BULLDOZER

BULLDOZER thumbnail-1
BULLDOZER photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
TIMAC
Model Number:
BULLDOZER 120
Condition:
New
Contact Supplier Request Quote Chat Now
Zhengzhou Timeway Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name TIMAC
Model Number BULLDOZER 120
Condition New
Moving Type Crawler Bulldozer
Machine Weight 15610kg
Dimension(Long * Breadth * High) 4904*3200*2890mm

BULLDOZER



NO DESCRIPTION  UNIT SPECIFICATON
1 MODEL / BULLDOZER 120
2 Engine Mode  / Dongfeng 6135K-2a
Type / Inline, vertical four-stroke cycle semi-open combustion chamber
Number of cylinder-bore*stroke mm 6-135*140
Rated horsepower/rpm kW/r/min 88.2/1500
Rated torque/rpm N.m/r/min 617Nm/1100RPM
Min. fuel consumption g/kw.h ≤238
3 Start method Type  / Electric starting motor
Starting motor V/kW 24V/6.6kW
Voltage/power
Battery  / 24V(12V*2)-195Ah
4 Lubrication system Lubrication type / Forced lubrication.
Cooling type / Water cooling
5 Cooling system Closed system  / through radiator, cooling fan, heat exchanger.
6 Air filter type / K2640X-LA
7   Main clutch / Dry type, multiple disc, non-constantly engaged.
Transmission system transmission / Spur gear, splash lubricated, 5 forward and 4 reverse speeds.
Bevel gear / Helical bevel gear, splash lubricated.
Steering clutch / Dry, multiple disc hand operated with hydraulic booster.
Steering brake / Dry, band brake, foot-actuated.
Final drive / Spur gear, double reduction, splash lubricated.
8 Travel Speed Forward 1st km/h 0~2.25
2nd km/h 0~3.61
3rd km/h 0~5.15
4th km/h 0~7.42
5th  km/h 0~10.34
reverse 1st km/h 0~2.7
2nd km/h 0~4.33
3rd km/h 0~6.18
4th  km/h 0~8.91
9 Under carriage Suspension system / Equalizer bar
Track tension  / Hydraulic-adjusted
Sprocket  Pics Segmented
Number of track rollers (each side) Pics 5(2 double 3 single)
Number of carrier rollers (each side) Pics  2
10 Track Type / Sealed single grouser
Track pitch mm 203
Number of track shoes pics 37
Track gauge mm 1880
Length of track on ground mm 2465
Track width mm 500
Ground pressure MPa 0.063
Ground clearance mm 300
11 Hydraulic system of work equipment Pump type / Gear pump CBL4140
Rated delivery  L/min 210
Control valve / Hand-operated, servo valve.
Working pressure MPa 12
Fuel tank L 110
Blade Max. lift above the ground mm 1020
Blade Max. drop below the ground mm 360
Max. lift speed m/s 0.35
Max. tilt mm 300
Pitch adjustment 0 53
12 blade type / Angle blade
Dimension  mm 3200*1130
Blade capacity m3 4
13 Min. turning radius m 3.3
15 Ground ability 0 30
16 Dimension without ripper mm 4904*3200*2890
17 Operating weight without ripper kg 15610
18 Ripper  mm Three shank ripper
  Max. dig below ground 540
  Max. lift above ground  320
