350mm Semi-Auto. Double-Column Metal Band Sawing Machine -- CH-350

Name: 350mm Semi-Auto. Double-Column Metal Band Sawing Machine -- CH-350
Brand: TIMAC
SKU: 140797772
Availability: InStock

Zhengzhou Timeway Machine Tool Co., Ltd.

US$ 3,850 - 4,350 MOQ: 1 Set

Key Specifications

Condition:

New

Brand Name:

TIMAC

Model Number:

CH-350

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name TIMAC

Model Number CH-350

Voltage As per request

Rated Power 3 kw

Dimension(L*W*H) 2230x1200x1670mm

Weight 1350kg

Certification CE norms; OHSAS18001

Warranty One year after deliery

Specifications

Horizontal Metal Band Sawing Machine
1. Max.cutting (Round): 350mm;
2.Max.cutting (Quadrate): 350x350mm
3.CE norms

350mm Semi-Auto. Double-Column Metal Band Sawing Machine -- CH-350

Parameter:

Specification		CH-350
Max.cutting	Round	350mm
capacity	Quadrate	350×350mm,
Saw blade	Speed	25/35/50/65/83
	Size	34×1.1×4250
	Guides	Carbide and bearing blade guides
	Cleaning	wire brush & flood coolant
	Tension	Manual
Motor output	Blade	3.0kw
	Hydraulic	0.75kw
	Coolant	0.075kw
Work feeding		Manual
Work Vice		Hydraulic
Machine Weight		1350kg
Packing Size(L×W×H)		2230×1200×1670
Container Loads		4SETS/20", 9SETS/40"

*** Standard Equipment:			**** Optional Equipment:
1. blade cleaning brush.			1. Variable vice pressure.
2. working light			2. Power roller table 2M long
3.Saw frame height selector gauge			3. Laser projector
4.Out feed with auxiliary plate table			4. Hydraulic blade tension
5.One piece of bi-metal saw blade.			5. Roller table 2M long
6.One set of tools with tool box			6. Inverter blade speed
7.Roller table 1M long
