Home > Manufacturing & Processing Machinery > Machine Tools > Grinding Machine > Siemens CNC Surface Grinding Machine / CNC Surface Grinder
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Surface Grinding Machine
CNC or Not:
CNC
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Small CNC Hydraulic Surface Grinding Machine / CNC Surface GrinderNegotiableMOQ: 1 Set -
Drill Bits Sharpening Grinder TM-70AUS$ 300 - 450MOQ: 1 Set
-
Rectificadora / Universal Cylindrical Grinder / Cylindrical Grinding MachineNegotiableMOQ: 1 Set
-
MY Series Mini Hydraulic Surface Grinding Machine / Surface GrinderNegotiableMOQ: 1 Set
-
Rectificadora / Mini Surface Grinding Machine / Surface GrinderNegotiableMOQ: 1 Set
Condition
New
Type
Surface Grinding Machine
CNC or Not
CNC
Brand Name
TIMAC
Model Number
SG-3063CNC2/CNC3,SG-30100CNC2/CNC3,SG-4080CNC2/CNC3,SG-40100CNC2/CNC3
Voltage
as customer's request
Power(W)
5.5kw
Weight
2800kg
Certification
CE & ISO
After-sales Service Provided
Engineers available to service machinery overseas
"Siemens SINUMERIK 808D Controller" CNC Hydraulic Surfacing Grinding Machine/CNC Surface Grinder
Product Description
Standard Accessories:
Coolant tank, Electronic magnetic chuck, Balancing arbor, Wheel flange, Wheel extractor, Leveling wedge and bolt Tools box and tools, Standard grinding wheel, Wheel dresser stand, Diamond pen, Build in electro magnetic chuck controller, Operation manual(English edition).
Optional Accessories:
Wheel balancing stand, Parallel dresser, Cooling system with magnetic separator, Cooling system with magnetic
separator & paper filter.
Parameter:
| Specification | Unit | SG-3063CNC2 | SG-30100CNC2 | SG-4080CNC2 | SG-40100CNC2 | |
| SG-3063CNC3 | SG-30100CNC3 | SG-4080CNC3 | SG-40100CNC3 | |||
| Table size(W×L) | mm | 305×635 | 305×1020 | 406×813 | 406×1020 | |
| Max.longitudinal travel | mm | 765 | 1130 | 910 | 1130 | |
| Max. cross travel | mm | 340 | 450 | |||
| Max.distance from spindle center to table surface | mm | 580 | ||||
| Electro magnetic chuck size | mm | 300×600 | 300×1000 | 400×800 | 400×1000 | |
| Table longitudinal movement | Speed | m/min | 5-25(CNC2);0.02-15(CNC3) | |||
| Feed of electro hand wheel | mm/div | 0.05(CNC3) | ||||
| Table transverse movement | Auto feed | mm/stroke | 0.1-8 | |||
| Rapid speed | mm/min | 0.05-1 | ||||
| Feed of handwheel | mm/div | 0.005 | ||||
| Wheelhead vertical movement | Auto feed | mm/stroke | 0.005-0.05 | |||
| Rapid speed | mm/min | 0.05-1 | ||||
| Feed of handwheel | mm/div | 0.005 | ||||
| Grinding wheel | Speed | rpm | 1450(50HZ),1750(60HZ) | |||
| Size(O.D×W×I.D) | mm | 350×40×127 | ||||
| Spindle motor | kw | 5.5 | ||||
| Hydraulic motor | kw | 2.2(CNC2) | ||||
| Cooling pump motor | kw | 0.125 | ||||
| Parallelism of working surfacing to mounting base | mm | 300:0.005 | ||||
| Roughness of working surface | μm | Ra≤0.63 | ||||
| Max. loading capacity of table (including magnetic chuck) | kg | 270 | 400 | 500 | 600 | |
| Height of machine | mm | 1890 | ||||
| Floor space(L×W) | mm | 3800×2200 | 4400×2200 | 3600×2400 | 4400×2400 | |
| Gross weight | kg | 1600 | 1800 | 3800 | 4300 | |
Tips:
*CNC2:2-axes (Y,Z)are CNC controlled;
*CNC3:3-axes (X,Y and Z) are CNC controlled.
