40mm Drilling Capacity Taladro Radial Drilling Machine / RD410

40mm Drilling Capacity Taladro Radial Drilling Machine / RD410 thumbnail-1
40mm Drilling Capacity Taladro Radial Drilling Machine / RD410 photo-1
US$ 1,500 - 12,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Drilling Speed:
32-2500 r.p.m
Contact Supplier Request Quote Chat Now
Zhengzhou Timeway Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
CNC or Not Normal
Drilling Speed 32-2500 r.p.m
Brand Name TIMAC
Model Number RD410
Voltage As per customer's request
Power(W) 2.2kw
Dimension(L*W*H) 187 x 97 x 217cm
Weight 1600kg
Certification ISO9001; CE

Specifications

Taladro Radial Drilling Machine
1) Max drilling dia. 40mm
2) Spindle travel:280mm
3) CE norms

Radial Drilling Machine RD310,RD410,RD413





40mm Drilling Capacity Taladro Radial Drilling Machine / RD410

Feature:



Taladro Radial Drilling Machine

1. The radial drilling machine is new series with diversified fuctions of product which has been designed and accomplished referring to international standard ISO in the recent years.

2. In this machine, hydraulic preselection speed and feed change mechanisms are adopted, the spindle head, radial arm and column are clamped by hydraulic clamping mechanisms.
3. The forward, reverse, stop(braking), as well as the setting of spindle  in neutral position are all controlled by a  single- lever, the machine has characteristics features of perfect performance, safe, reliable  and easy operation,  convenient  maintenance, high-accuracy, ample rigidity and long service long.
4. It is used for drilling, counter boring, spot facing, reaming, tapping and boring, widely used in every department of mechaninal machining.



Parameter:



Specification

RD310

RD410

RD413

Max.Drilling capacity (mm)

32

40

40

Distance spindle axis to column generating line (mm)

300-1000

300-1000

300-1300

Diameter of column (mm)

240

240

300

Spindle taper

MT4

MT4

MT4

Spindle travel (mm)

280

280

280

Spindle speeds range (r/min)

32-2500

32-2500

32-2500

Spindle speeds steps

16

16

16

Range of Spindle feeds (mm/r)

0.10-1.25

0.10-1.25

0.10-1.25

Spindle feeds steps

8

8

8

Max.Distance spindle nose to working surface of base (mm)

220-1000

220-1000

300-1320

Dimension of worktable (mm)

600×450×450

600×450×450

600×450×450

Dimension of base (mm)

1710×800×160

1710×800×160

2050×900×200

Overall Size (mm)

1760×800×2050

1760×800×2050

2100×900×2300

Power of Main motor (KW)

2.2

2.2

3

G.W/N.W (kg)

2100/1600

2100/1600

3800/2500

Packing dimension (cm)

187×97×217

187×97×217

236×117×258
