Specifications
Industrial Series Radial Drilling Machine1. Max drilling dia 80mm
2. Spindle travel:400mm
3. CE norms
80mm Industrial Series Radial Drilling Machine
Feature:
Industrial Series Radial Drilling Machine
1. The radial drilling machine is new series with diversified fuctions of product which has been designed and accomplished referring to international standard ISO in the recent years.
2. In this machine, hydraulic preselection speed and feed change mechanisms are adopted, the spindle head, radial arm and column are clamped by hydraulic clamping mechanisms.
3. The forward, reverse, stop(braking), as well as the setting of spindle in neutral position are all controlled by a single- lever, the machine has characteristics features of perfect performance, safe, reliable and easy operation, convenient maintenance, high accuracy, ample rigidity and long service long.
4. It is used for drilling, counter boring, spot facing, reaming, tapping and boring, widely used in every department of mechaninal machining.
Parameter:
Specification |
Unit |
RD816Q |
RD820Q |
RD825Q |
Max. drilling diameter |
mm |
80 |
||
| Throat depth | mm |
450-1600 |
450-2000 |
450-2500 |
Distance spindle -base |
mm |
348-1548 |
||
Spindle taper |
Morse |
No.6 |
||
Spindle travel |
mm |
400 |
||
Number of spindle speed |
|
16 |
||
Range of spindle speed |
r/min |
16-1250 |
||
Number of spindle feeds |
|
16 |
||
Range of spindle feeds |
mm/r |
0.04-3.2 |
||
Power of main motor |
kw |
7.5 |
||
Net weight |
kg |
6700 |
7000 |
7400 |
Gross weight |
kg |
7700 |
8000 |
8400 |
Overall dimension( LxWxH) |
cm |
290x125x344 |
311x125x344 |
406x125x344 |
