Help CenterHeavy-duty Horizontal Lathe/Universal Heavy-duty Lathe
Related Products
-
Heavy-duty Horizontal Lathe Machine/Universal Heavy-duty Horizontal Lathe FL-1250ANegotiableMOQ: 1 Set -
800 Swing Horizontal Metal Working Lathe DL-800BUS$ 8,500 - 12,000MOQ: 1 Set
-
Heavy-duty Horizontal Lathe Machine/Universal Heavy-duty Horizontal LatheNegotiableMOQ: 1 Set
-
Precision Gap-bed Lathe/High Speed Gap-bed LatheNegotiableMOQ: 1 Set
-
Precision Gap-bed Lathe/Universal Gap Bed Lathe/Precision Bench Lathe FL-600CUS$ 3,000 - 7,985MOQ: 1 Set
Specifications
1. Horizontal gap-bed lathe;2. Large spindle bore 120mm;
3. Constant spindle accuracy;
4. Rapid removing device.
Features:
1. The series of Horizontal (Gap-Bed) Lathe Machine are high speed and large spindle hole universal lathes.
2. It has a wide range in machining the thick bars and the pipes of the large diameter below Ø118mm, it is suitable for machining all kinds of swivelling workpiece.
3. Large spindle bore (Ø120mm).
4. High accuracy and low noise for its hardened and ground gears in the headstocks.
5. New slide bearing patented by the state has good antivibrition and constant spindle accuracy.
6. According to the user’s order, the lengthened machine can be equipped with double aprons.
7. Rapid removing device used by apron with high efficiency.
Standard accessories:
Three jaw chuck 1 set,
Center sleeve,
M.T No.5 center 2 set,
Oil gun 1 set,
Tools 1 set,
Foundation screws 1 set, Wedge nuts 1 set,
Optional manual 1 set
Optional accessories:
Steady support, Follow rest, Four jaw chuck, Face plate, Drive plate
Specification |
Unit |
DL-630 |
DL-710 |
DL-800 |
|
Capacity |
Max. swing diameter over bed |
mm |
630 |
710 |
800 |
Max. swing diameter over cross slide |
mm |
390 |
460 |
550 |
|
Max. swing on gap |
mm |
830 |
910 |
1000 |
|
Width of bed |
mm |
410 |
|||
Max. length of workpiece |
mm |
1000 1500 2000 3000 4000 5000 6000 8000 |
|||
Spindle |
Spindle nose |
|
D11 |
||
Spindle bore diameter |
mm |
120 |
|||
Taper of spindle bore |
|
1:20 |
|||
Range of spindle speed |
r.p.m |
12-1000(18 kinds) |
|||
Feeds |
Longitudinal feeds range |
mm/r |
0.082-1.59(35 kinds) |
||
Transverse feeds range |
mm/r |
0.027-0.522(35 kinds) |
|||
Metric threads range |
mm |
1-192(57 kinds) |
|||
Inch threads range |
T.P.I |
2-24(30 kinds) |
|||
Module threads range |
M.P |
0.25-48(40 kinds) |
|||
Pitch threads range |
D.P |
1-96(36 kinds) |
|||
Tailstock |
Taper of tailstock sleeve |
|
Morse No.5 |
||
Travel of tailstock sleeve |
mm |
250 |
|||
Diameter of tailstock sleeve |
mm |
100 |
|||
Motors |
Main motor power |
kw |
7.5 |
||
Rapid motor power |
kw |
0.25 |
|||
Coolant pump power |
kw |
0.125 |
|||
