Lab Equipment SYJ-160 Low Speed Diamond Saw Weiyi Brand

Lab Equipment SYJ-160 Low Speed Diamond Saw Weiyi Brand thumbnail-1
Lab Equipment SYJ-160 Low Speed Diamond Saw Weiyi Brand thumbnail-2
Lab Equipment SYJ-160 Low Speed Diamond Saw Weiyi Brand photo-1
Lab Equipment SYJ-160 Low Speed Diamond Saw Weiyi Brand photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Applicable Material:
Crytal, Glass, Metal, plastic, Rubber, Stone
Cutting Thickness:
150MM
Contact Supplier Request Quote Chat Now
Laizhou Weiyi Experimental Machinery Manufacture Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Applicable Material Crytal, Glass, Metal, plastic, Rubber, Stone
Cutting Thickness 150MM
Cutting Area 150MM
Cutting Speed 20--600rpm stepless speed adjust
CNC or Not No
Cooling Mode Air Cooling
Place of Origin Shandong, China
Brand Name weiyi
Model Number SYJ-160
Certification CE, ISO
After-sales Service Provided Engineers available to service machinery overseas

Lab equipment SYJ-160 Low Speed Diamond Saw weiyi brandLab equipment SYJ-160 Low Speed Diamond Saw weiyi brand

Detail



Model:

SYJ-160 Low Speed Diamond Saw

Brief Introduction:

SYJ-160 Low Speed Diamond Saw  is specialized  designed to material researchers, the products sells to research institutes, universities and  research department of famous companies, small and medium-sized companies for the relevant material analysis. Many artificial crystal precision cutting also can use this machine.

Main

Feature:

Used for precision cutting the material sample, high torque, running steady, can cut all kinds of materials and the thickness are 0.1mm. Suitable for samples' follow-up thinning, polishing and various operation.

The different between SYJ-160 and SYJ-150 is the former can use various blades of 150mm(outside diameter). It's good for cutting bigger samples.  Original equips with digital micrometer.

Technical

Parameter:

1. Speed range:20-600RPM stepless speed adjust

2. Voltage:AC 110V/220V
3. Position accuracy:0.01mm( Mechanical and digital display )
4. Two dimension, angle adjustment: 360(H),(+/-)15(V)
5. Max. travel distance:50mm(Fine adjustment travel distance 25mm)
6. Max dia. wafer blade:150mm(6 inches)
7. Automatic shut off:allowed unattended
8. Digital display axis RPM

Specification:

Size:400 x300 x30mm  Weight:14.5kg

Standard Accessories:

1

Adjustment sample holder

1 set



2

Mini-vise

1 pc



3

O-ring of Driving Motor

2 pcs



4

Full Sintered Diamond Blade  (Φ150×12.7×0.55mm)

1 pc



5

Electroplating diamond blade(Φ150×12.7×0.4mm)

2 pcs



6

Sic blade(Φ150mm×12.7mm×0.4mm)

5 pcs



7

Al2O3 blade(Φ150mm×12.7mm×0.4mm)

5pcs



8

Resin ceramic block(50mm×50mm×12mm)

2pcs



9

Aluminum Plate(25mm×50mm×7mm)

2 pcs



10

Wax for gluing sample

2 pcs



11

Blade clamps(Φ35mm, Φ46mm,Φ62mm)

3 set





Optional Accessories :

1. Edge sintered Diamond Blade:Φ150x12.7x0.55
2. Full sintered Diamond Blade:Φ150x12.7x0.50
3. Sic blade:Φ150x12.7x0.55
4. Al2O3 blade:Φ150x12.7x0.55

5. Electroplating diamond blade:Φ150x12.7x0.40

6. (Optional)All kinds of blades:Φ100x12.7x0.4
Lab equipment SYJ-160 Low Speed Diamond Saw weiyi brandLab equipment SYJ-160 Low Speed Diamond Saw weiyi brand
