Foton Auman 6x4 hydraulic bin lifter truck Euro 3 lifter truck1. hydraulic crane
escopic & folding boom optional
Foton Auman 6x4 hydraulic bin lifter truck Euro 3 lifter truck
1. Technical Features
I.Main specifications | ||||||||
Product model,name |
CLW5250JSQB3T ruck With Crane |
|||||||
Total weight(Kg) |
25000 |
Driving type |
6 X 4 |
|||||
Payload (Kg) |
11500,11620 |
Overall dimension (mm) |
10750×2500×3750 |
|||||
Curb weight(Kg) |
13305,13185 |
Box internal dimension(mm) |
7000,7200×2294×550,800 |
|||||
cab seats (man) |
3 |
Front/rear hang(mm) |
1532/3193 |
|||||
Approach/departure angle (°) |
11/9 |
Wheelbase(mm) |
4725+1300 |
|||||
Number of axles |
3 |
Max speed(Km/h) |
85 |
|||||
Axle load(Kg) |
7000/18000 |
|||||||
II.Crane specification | ||||||||
Crane model |
SQ10SA2, SQ8SA3 |
Crane brand |
CLW |
|||||
Max lifting weight(kg) |
10000,8000 |
Max lift height(m) |
11.5,14.5 |
|||||
Working radius(m) |
9.5,12.5 |
Outrigger (pcs) |
2 |
|||||
III.Chassis specifications | ||||||||
Chassis model |
BJ5257GNFJH-S1 |
Chassis category |
the truck classis (class 2) |
|||||
Brand name |
Foton Auman |
Manufacture |
Beijing foton Daimler automotive co., LTD |
|||||
Overall dimension(mm) |
10067×2490×3010 |
Tires No. |
10 |
|||||
Approach/departure angle (°) |
11/12 |
Tire specification |
10.00R20 16PR |
|||||
Steel spring number |
9/12 |
Front track(mm) |
1930 |
|||||
Type of fuel |
Diesel |
Rear track(mm) |
1860/1860 |
|||||
Emission standard |
GB17691-2005 Euro Ⅲ,GB3847-2005 |
|||||||
Engine model |
Engine manufacture |
Displacement(ml) |
Power(Kw) |
|||||
|
SC8DK240Q3 SC9DK270Q3B1 |
Shanghai diesel engine co., LTD Shanghai diesel engine co., LTD |
8270 8820 |
177 199 |
|||||
IV.Functions | ||||||||
Special used for cargo lifting and transportation at stations,warehouse,docks,construction sites and filed resuce. | ||||||||
3.Product Image
Various of Crane Truck For Sale
The above information is just for your reference. We can manufacture the trucks as per your request.
3.Certification
4.About Us
We are a professional manufacture for special automobiles, have export license, and our products have engaged in a large area of the overseas market, having a bussines backgroud of some years, good reputation, all of the products have workable price, excellent quality and prompt delivery.
5.Quality
The above goods shall be in accordance with the Manufacturer’s standards and Chinese export standards.
6.TIME OF DELIVERY
Within 15-20 working days from the receipt date of deposit payment.
7.GUARANTEE PERIOD
The guarantee period for all equipment/accessories and spare parts shall be valid 12 months from Shipment or 10000klm.
For more information,please contact me! We will do our best to work with you to get the job done.
