dongfeng 15ton 6 x 4 flatbed truck flatbed
[Main specifications] | |||||||
Product model,name |
Dongfeng flatbed truck with crane |
||||||
Gross vehicle weight(kg) |
24700 |
Drive type |
6 x 4 |
||||
Payload(kg) |
8420 |
cab seats (man) |
3 |
||||
Curb weight(Kg) |
13985 |
Overall dimension (mm) |
10790×2495×3630 |
||||
Approach/departure angle (°) |
28/10 |
Box internal dimension(mm) |
7190×2294×550 |
||||
Number of axles |
3 |
Front/rear hang(mm) |
1245/3495 |
||||
Axle load(Kg) |
6900/17800 |
Wheelbase(mm) |
4350+1300 |
||||
Max speed(Km/h) |
85 |
Loading bearing surface dimension(L*W mm) |
7000×2500 |
||||
[Chassis specifications] | |||||||
Chassis model |
EQ5253GFJ2 |
Brand name |
Dongfeng |
||||
Manufacturer |
Dongfeng Motor Corporation |
Tires No. |
10 |
||||
Approach/departure angle (°) |
28/15 |
Tire specification |
10.00-20 |
||||
Steel spring number |
9/10 |
Front track(mm) |
1940 |
||||
Fuel type |
Diesel |
Rear track(mm) |
1860/1860 |
||||
Emission standard |
EURO III |
Transmission |
8 gears Air brake |
||||
Cabin |
Luxurious interior trim, seat, and sleeper, with power steering, air conditioning can be equiped if customer requires. |
||||||
Engine model |
Engine manufacturer |
Displacement(ml) |
Power(Kw) |
||||
B210 33 |
Dongfeng Cummins Engine Co., Ltd |
5900 |
155 |
||||
[Crane specification] | |||||||
Crane model |
SQZ32 |
Crane brand |
XCMG |
||||
Type of Crane |
Folding boom crane |
Crane weight (kg) |
608 |
||||
Max lifting weight(kg) |
2000 |
Max lift height(m) |
7.5 |
||||
Working radius(m) |
4.78 |
Operation method |
Side control |
||||
Number of arms |
2 |
Outrigger (pcs) |
2 |
||||
[Functions] | |||||||
|
The truck consists of chassis, box, power take-off and crane, achieving cargo lifting and moving through hydraulic lifting and telescopic system. In general, H-type outrigger is equipped to realize its stability. To be further strengthened stability of the truck, rear outrigger also can be equipped if the customer require. The truck can 360 ° continuously rotate. Mainly used for transport for excavator, wheel loader, harvest ect undisassemble machines. | |||||||
