SINOTRUK 6cbm concrete mixer truck with 4*2 driver
Main specifications | ||||
Product model,name | ZZ5164GJBH3615C Concrete mixer truck | |||
Gross weight(Kg) | 16000 | Drive type | 4x2 | |
Payload(Kg) | 7150 | Overall demension(mm) | 6915×2480×3450 | |
Curb weight(Kg) | 8720 | Cab seats(man) | 3 | |
Approach/departure angle(°) | 30/32 | Front/rear hang(mm) | 1250/2065 | |
Number of axles | 2 | Wheelbase(mm) | 3800 | |
Axle load(Kg) | 6000/10000 | Max speed(Km/h) | 84 | |
Chassis specifications | ||||
Chassis model | ZZ1164H3615C | Manufacture | China Heavy Duty Truck Group Jinan Commercial Vehicle Co., Ltd. | |
Brand name | SINOTRUK | Overall dimension(mm) | 6510×2470×2880 | |
Tire specification | 10.00-20 | Tires No. | 6 | |
Steel spring number | 11/10+10 | Front track(mm) | 2020 | |
Fuel type | Diesel | Rear track(mm) | 1860 | |
Emission standard | Euro III | Transmission | 10 gears | |
Cabin | Luxury interior and Instrument bar, with air conditioning and sleeper. | |||
Main engine model | Engine manufacutre | Displacement(ml) | Power(kw) | |
YC6J220-33 | Guangxi Yuchai MachineryCo., Ltd. | 6494 | 162 | |
Concrete mixer truck performance | ||||
Tank volume(m3) | 6 | Material of tank | Q345 | |
Pump | Import | Motor | Import | |
Reducer | Import | Surplus ratio | ≤1.0% | |
Water tank volume(L) | 350L | The supplied water method | Pneumatic | |
Concrete mixer truck features | ||||
This is mainly used for the modern roads and major construction projects, which is for ensure the quality of the concrete poured by stirring the concrete slowly and continuously during transporting or one the construction site. | ||||
Image as below:
Production equipment introduction
