DongFeng 6*4 cement mixer truck weight 8cbm concrete mixer truck
340hp diesel engine
mixing volume 8-10M3
Italy hydraulic system
Dongfeng concrete truck mixer truck
Concrete trucks mixer trucks are made to transport and mix concrete up to the construction site. They can be charged with dry materials and water, with the mixing occurring during transport. With this process, the material has already been mixing. The concrete mixing transport truck maintains the material's liquid state through agitation, or turning of the drum, until delivery.
Main specifications | ||||
Product model,name | DFL5250GJBA Concrete mixer truck | |||
Gross weight(Kg) | 25000 | Drive type | 6 x 4 | |
Payload(Kg) | 11805,11870 | Overall demension(mm) | 8100×2500×3750 | |
Curb weight(Kg) | 13000 | Cab seats(man) | 2,3 | |
Approach/departure angle(°) | 30/18,30/20,30/19 | Front/rear hang(mm) | 1460/1910 | |
Number of axles | 3 | Wheelbase(mm) | 3650+1350 | |
Axle load(Kg) | 7000/18000 | Max speed(Km/h) | 80 | |
Chassis specifications | ||||
Chassis model | DFL5250GJBA | Manufacture | Dongfeng Motor Co., Ltd. | |
Brand name | DongFeng | Overall dimension(mm) | 8070×2500×3030 | |
Tire specification | 11.00R20 | Tires No. | 10 | |
Steel spring number | 25/30,25/32 | Front track(mm) | 2040 | |
Fuel type | Diesel | Rear track(mm) | 1860 | |
Emission standard | Euro III | Transmission | 9 forward gear | |
Cabin | Luxury interior and Instrument bar, with air conditioning and sleeper. | |||
Engine model | Engine manufacutre | Displacement(ml) | Power(kw) | |
L340 30 | Dongfeng Engine Co., Ltd. | 8900 | 250 | |
Concrete mixer truck performance | ||||
Tank volume(m3) | 8 | Material of tank | Q345 | |
Pump | Import | Motor | Import | |
Reducer | Import | Surplus ratio | ≤1.0% | |
Water tank volume(L) | 350L | The supplied water method | Pneumatic | |
Concrete mixer truck features | ||||
This is mainly used for the modern roads and major construction projects, which is for ensure the quality of the concrete poured by stirring the concrete slowly and continuously during transporting or one the construction site. | ||||
Packaging &Shipping
1.About the package of our trucks,usually it is nude that covered with wax.And it also can be packed as your need.
2.About the shipping,there are many ways,such as Ro-Ro Ship / Bulk transport / Container packing / SKD / etc. And it can be offered according to your request.
Our services
| A.Delivery time | ||||||||
| Usually within 10 to 25 days after getting your deposit. And the accurate time depends on your QTY. | ||||||||
| B.Terms of payment | ||||||||
| 30% of contract amount must be paid by T/T before the production. After the completed trucks are checked and confirmed well by our clients, the balance shall be paid before the shipment. | ||||||||
| C.Truck warranty to solve our clients’ worries when purchasing | ||||||||
| The warranty period is one year or 25000KM that drove under normal operation and control since our clients get the trucks. And we can supply maintenance for the whole life. |
Product show:
