6x4 Mixer Trucks for Sale

Name: 6x4 Mixer Trucks for Sale
Brand: Sinotuck HOWO
SKU: 140782088
Availability: InStock

Hubei Ocean Special Automobile Co., Ltd.

US$ 61,000 - 70,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Hubei, China

Brand Name:

Sinotuck HOWO

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Hubei, China

Brand Name Sinotuck HOWO

Model Number ZZ5257GJBN3847C

Motor Power 249KW

Mixing Power Ref below information

Charging Capacity Ref below information

Reclaiming capacity 1 M3

Speed of Mixing Drum Ref below information

Water Supply Mode manual

Working Cycle Period Ref below information

Discharge Way manual

Outline Dimension 9760*2500*3990

After-sales Service Provided Overseas service center available

6x4 mixer trucks for sale

we are factory!

Main specifications
Product model,name	ZZ5257GJBN3847C Concrete mixer truck
Gross weight(Kg)	25000		Drive type	6x4
Payload(Kg)	11770,11650		Overall demension(mm)	9040×2496×3850
Curb weight(Kg)	13100,13220		Cab seats(man)	2
Approach/departure angle(°)	16/26,24		Front/rear hang(mm)	1500/2340
Number of axles	3		Wheelbase(mm)	3800+1350
Axle load(Kg)	7000/18000		Max speed(Km/h)	90,102
Chassis specifications
Chassis model	ZZ1257N3847C		Manufacture	China National Heavy Duty Truck G roup Co., Ltd
Brand name	Sinotruk		Overall dimension(mm)	8600×2496×3048
Tire specification	12.00R20		Tires No.	10
Steel spring number	9/12,10/12,4/12		Front track(mm)	2041
Fuel type	Diesel		Rear track(mm)	1830
Emission standard	Euro III		Transmission	10 forward gear
Cabin	Luxury interior and Instrument bar, with air conditioning and sleeper.
Engine model	Engine manufacutre	Displacement(ml)		Power(kw)
WD615.95C	China National Heavy Duty Truck G roup Co., Ltd	9726		249
Concrete mixer truck performance
Tank volume(m³)	10	Material of tank		Q345
Pump	Import	Motor		Import
Reducer	Import	Surplus ratio		≤1.0%
Water tank volume(L)	350L	The supplied water method		Pneumatic
Concrete mixer truck features
This is mainly used for the modern roads and major construction projects, which is for ensure the quality of the concrete poured by stirring the concrete slowly and continuously during transporting or one the construction site.
