FAW 10CBM concrete mixing truck,concrete mixer truck dimensions
I. Vehicle Parameter | ||||||||||||||||
1, model,name |
CA5250GJBP66K2L1T1E concrete mixer truck |
|||||||||||||||
2, tanker capacity |
10 m³ |
|||||||||||||||
3,manufacturer |
Hubei ChengLi Special Automobile Co.,Ltd (IN CHINA) |
|||||||||||||||
4, Overall dimension |
9210×2495×3900 mm |
5,curb weight |
14590 Kg |
|||||||||||||
6, cab seats |
3 |
7,Max speed |
88km/h |
|||||||||||||
8,Transmission |
8 forward gear,1 reverse gear |
|||||||||||||||
9,Approach/departure angle |
24/18 ° |
10,front/ rear hang |
1500/2560mm |
|||||||||||||
11,steering type |
Left- hand drive( right-hand drive can opt) |
|||||||||||||||
12,Special device |
Driving system |
Reducer |
Italy Pump |
|||||||||||||
Hydraulic pump |
Italy Pump |
|||||||||||||||
Hydraulic motor |
Italy Pump |
|||||||||||||||
Radiator |
China Kaitong |
|||||||||||||||
Water supplying system |
Water tank capacity |
200L |
||||||||||||||
Supplying type |
Atmospheric pressure |
|||||||||||||||
operating type |
Flexible shaft |
|||||||||||||||
II. Chassis parameter | ||||||||||||||||
1, Chassis model |
CA1250P66K2L1T1S2E |
2, Brand name |
FAW |
|||||||||||||
3,manufacturer |
FAW Motor Co.,Ltd. |
|||||||||||||||
4,Drive type |
6*4 |
5,Wheel base |
3800+1350 mm |
|||||||||||||
6,Front track base |
2050 mm |
7,Rear track base |
1830mm |
|||||||||||||
8,Tire specification |
11.00R20-16PR |
9,tyre number |
10+1(spare tyre) |
|||||||||||||
10,axle load |
7000/18000 kg |
11,axle number |
3 |
|||||||||||||
III. Engine parameter | ||||||||||||||||
1,engine type(emission/power) |
CA6DL2-35E3( 8600ml / 370kw ) |
|||||||||||||||
2, Engine manufacturer |
China First Automobile Group Corporation |
|||||||||||||||
3,Fuel type |
Diesel |
4,Emissions standards |
Euro3 |
|||||||||||||
Production equipment introduction
