SINOTRUK HOWO Brand! 12 CBM Concrete Mixer Truck Trailers

Name: SINOTRUK HOWO Brand! 12 CBM Concrete Mixer Truck Trailers
Brand: SINOTRUCK HOWO
SKU: 140782062
Availability: InStock

Hubei Ocean Special Automobile Co., Ltd.

US$ 60,000 - 69,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Hubei, China

Brand Name:

SINOTRUCK HOWO

Payment & Shipping

Payment Methods:

Port of Shipment:

any ports available

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Hubei, China

Brand Name SINOTRUCK HOWO

Model Number ZZ5317GJBN3667D1

Motor Power Find below tech specification

Mixing Power Find below tech specification

Charging Capacity Find below tech specification

Reclaiming capacity Find below tech specification

Speed of Mixing Drum Find below tech specification

Water Supply Mode Find below tech specification

Working Cycle Period Find below tech specification

Discharge Way Automatic

Outline Dimension ZZ5317GJBN3667D1

After-sales Service Provided Overseas service center available

SINOTRUK HOWO Brand! 12 CBM concrete mixer truck trailers

Product Description

1.running stable

2.quality reliable
3.inner environmental comfortable
4.energy efficient
5.famous brand chassis

Main specifications
Product model,name	ZZ5317GJBN3667C1 Concrete mixer truck
Gross weight(Kg)	31000		Drive type	6 x 4
Payload(Kg)	14320,12670		Overall demension(mm)	11850×2496×3995
Curb weight(Kg)	16550,18200		Cab seats(man)	2
Approach/departure angle(°)	16/12,16/11,16/9		Front/rear hang(mm)	1500/3375
Number of axles	4		Wheelbase(mm)	1800+3600+1350
Axle load(Kg)	6500/7000/17500		Max speed(Km/h)	90
Chassis specifications
Chassis model	ZZ1317N3667C1		Manufacture	China National Heavy Duty Truck G roup Co., Ltd
Brand name			Overall dimension(mm)	10175×2496×3025
Tire specification	12.00R20		Tires No.	12
Steel spring number	4/4/-,11/11/-		Front track(mm)	2041
Fuel type	Diecel		Rear track(mm)	1830
Emission standard	Euro III		Transmission	10 forward gear
Cabin	Luxury interior and Instrument bar, with air conditioning and sleeper.
Main engine model	Engine manufacutre	Displacement(ml)		Power(kw)
WD615.96E	China National Heavy Duty Truck G roup Co., Ltd	9726		276
Concrete mixer truck performance
Tank volume(m3)	12	Material of tank		Q345
Pump	Import	Motor		Import
Reducer	Import	Surplus ratio		≤1.0 %
Water tank volume(L)	150L	The supplied water method		Pneumatic
Concrete mixer truck features
This is mainly used for the modern roads and major construction projects, which is for ensure the quality of the concrete poured by stirring the concrete slowly and continuously during transporting or one the construction site.
