QY40K truck crane adopts full luxury cab with large view and new orthodrome streamline operating cab, which is good looking. Adopt five-segment oval rope retractable boom with double-cylinder and two-segment jib, greatly improving the working scope of the machine. The design of the streamline boom head is in keeping with the style of the machine. The boom and jib adopt new connection method, which is convenient to dismantle and install. It is equipped with the high-power environment protection engine, improving the chassis power and the trafficability.
Truck crane QY40K | ||
Dimensions | Overall length | 13050mm |
Overall width | 2800mm | |
Overall height | 3430mm | |
Weight | Dead weight in travel state | 40400kg |
Front axle load | 14500kg | |
Rear axle load | 25900kg | |
Power | Engine model | WD615.334 |
Engine rated power | 247/2200 Kw(r/min) | |
Engine rated torque | 1350/1400 N.m(r/min) | |
Travel | Max.travel speed | 75Km/h |
Min. turning diameter | 24m | |
Min. ground clearance | 285mm | |
Approach angle | 16 | |
Departure angle | 11 | |
Max. Grade ability | 46% | |
Fuel consumption of per 100km | 46L | |
Lifting performance | Max. total rated lifting load | 40T |
Min. rated working radius | 3000mm | |
Max.lifting torque | 1400kn.m | |
Turning radius at turn table tail | 3482mm | |
Base boom | 10.7m | |
Full-extend boom | 40.1m | |
Full-extend boom+Jib | 55.1m | |
Outrigger longitudinal distance span | 5.65m | |
Outrigger lateral distance span | 6.6m | |
Working speed | Boom elevating time | 88s |
Boom full extension time | 180s | |
Max. slewing speed | 2 r/min | |
Main winch max. speed(single line) | 110m/min | |
Auxiliary winch max.speed(single line) | 110m/min | |
Payment Terms: T/T 30% in advance, and the balance by T/T after leaving the factory..
Delivery time: within 30 days after receiving the deposit.
1. Guaranty time: 12 months (calculating from the date the machine leave the port of loading) or 1200 working hours, whichever comes first.
2. Provide maintenance instruction, parts list, packing list, accessories and tools free of charge when send the machine to you.
3. Provide the parts free of charge in the guaranty time if the parts cannot work well.
4. Excess the guaranty; you can easily to buy from us with cost price anytime.
