90 HP TRACTOR SPEC.
Model |
TY904 |
Type |
4WD Wheeled Type |
Length(including after the flag) |
4396 |
Width |
2038mm |
Height (up to the top silencer) |
2810mm |
Rear Wheel Tread |
1520mm |
Axle Base |
2316mm |
Min. Ground Clearance |
350mm |
Structure weight |
2940kgs |
Front ballast |
250 |
Rear ballast |
170kg,340kg,510kg,(optional) |
Rated traction force |
1520kgs |
Engine Model |
PERKINS 1004-4TRT90N01 |
Engine Type |
4-Cylinder |
Cooler type |
Water |
Stroke |
4 Stroke |
Rated Power |
66.2 +/-5%/12h |
Rated Speed |
66.2/2300kw/r/min |
Maximum torque/speed(N.m(r/min) |
380+/-5%/1500-1700 |
Mini speed |
750+/-30 |
Fuel |
Diesel |
Front Wheel Tyre |
8.3-24 |
Rear Wheel Tyre |
14.9-30 |
Clutch |
Dual-stage clutch |
Steering |
Power steering |
Transmission Type |
8+2 or (8+2)×2 with creeper shift |
Suspension Type |
3-point links |
Type and Rev |
Semi-independent Type 540/1000 |
Spline Size |
F35 Rectangle Spline with 6 teeth |
Advantages :
- The streamline design makes it an elegant appearance.
- The tires are made of multi-ply natural rubber which ensures its wear resistance performance.
- Front axel is strong and robust. Well-known brand Carraro is at your option.
- Our high quality diesel engine is powerful and environmental friendly. Also, perkins engine is optional.
- Independent hydraulic fuel system reduces maintenance cost.
- Both clutch and brakes system are light and easy to control.
- Reinforced chassis greatly increases pulling force.
- Well-sealed cabin with low noise.
- A comprehensive production line consists of casting, forging, CNC machining and final assembling.
- The replacements are within your reach for more than ten years.
- Quality control processes are in place to ensure all our parts are made up to high standards.
- The tractor evolves rapidly with time and it is your best choice for performance and reliability.
