Home > Transportation > Tractor & Parts > Tractor > China 35HP Tractor With CE JT354 Hot Sale, 4X4WD or 4X2WD Cheap Farm Tractor

China 35HP Tractor With CE JT354 Hot Sale, 4X4WD or 4X2WD Cheap Farm Tractor

China 35HP Tractor With CE JT354 Hot Sale, 4X4WD or 4X2WD Cheap Farm Tractor thumbnail-1
China 35HP Tractor With CE JT354 Hot Sale, 4X4WD or 4X2WD Cheap Farm Tractor thumbnail-2
China 35HP Tractor With CE JT354 Hot Sale, 4X4WD or 4X2WD Cheap Farm Tractor photo-1
China 35HP Tractor With CE JT354 Hot Sale, 4X4WD or 4X2WD Cheap Farm Tractor photo-2
US$ 1 - 2 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Weifang Jintai Power Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO OR SHANGHAI CHIAN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Certificate CE
Brand Name JINTAI
Model Number TY354
Place of Origin Shandong, China
After-sales Service Provided Engineers available to service machinery overseas



Product Description



Model

TY354

Type

4×4     Wheeled  Type

Over  all  dimension

Length

3168

Width

1560

Height

1980

Tread

Front Wheel

1000 /1200Fixed

Rear Wheel

1000/1200Adjusted

Wheel Base

1686/1772

Min.Ground Clearance

223

(kg)Dry Mass

Six Shift : 1270/Eight Shift:1300

Engine

Model

JD3100or LD4L22


3or 4 cylinder ,Vertical, Water Cooled and 4-stroke

(kw)Rated Power

25.7

(r/min)Rated Rev.

2350

Fuel

Diesel  Oil

Tire

Front Wheel

6.0-16

Rear Wheel

9.5-24

Clutch

Dry-friction,single stage or Dry-friction,Two Stage

Steering

Mechanical Type/Mechanical Type or Hydraulic Type

Transmission Box

(3+1)×2or(4+1)×2or(4+1)×2×2(with  creeping Shift)

Suspension Type

Post Positioned Tri-point suspension Cat a orⅠ

PTO shaft

(r/min)                       Type and Rev

Non-independent Type 540/720 or Semi-independent Type 540/1000,540/720

Spline Size

135Rectangle Spline With 6 teeth  (6×28.91×34.79×8.69)

Structure and specification are subject to change without notice.





Specifications

4-cylinder diesel
dual stage clutch
transmission box type:(4+1)X2 mechanical
Creeping shift, hydraulic output

Brief introduction & Advantage



This series product is a middle-horsepower shaft-connected agricultural tractor. It can be used not only in dry or paddy field but also transportation. It is equipped with 4-cylinder diesel engine ,(4+1)X2 mechanical gear box, dual stage clutch . It has the characteristics of powerful, compact structure, easy operation, nice outlook, easy maintenance, high adaptability. Creeping shift, hydraulic output, air braking can be equipped according to users demand.





Photos

 China 35HP tractor with CE JT354 hot sale, 4X4WD or 4X2WD cheap farm tractorChina 35HP tractor with CE JT354 hot sale, 4X4WD or 4X2WD cheap farm tractorChina 35HP tractor with CE JT354 hot sale, 4X4WD or 4X2WD cheap farm tractorChina 35HP tractor with CE JT354 hot sale, 4X4WD or 4X2WD cheap farm tractorChina 35HP tractor with CE JT354 hot sale, 4X4WD or 4X2WD cheap farm tractorChina 35HP tractor with CE JT354 hot sale, 4X4WD or 4X2WD cheap farm tractorChina 35HP tractor with CE JT354 hot sale, 4X4WD or 4X2WD cheap farm tractor



 China 35HP tractor with CE JT354 hot sale, 4X4WD or 4X2WD cheap farm tractorChina 35HP tractor with CE JT354 hot sale, 4X4WD or 4X2WD cheap farm tractor



Why choose us?

1. More than 500 workers.

2. With the occupying area of 2500 square meters.

3. More than 10 years experiences in the industry of construction machine and agricutural machine.

4. Competitive price and high quality.

5. One hour reaches Qingdao port.

6. All the inquiries will be replied within 12 hours
