Specifications
Brand-name PartsProduct Performance
Prompt Delivery
Product Description
Diesel generator
1.Factory directly supply
2.CE&ISO9001 approved
3.Various kinds&accept OEM design
4.Aviation Technology,Military Quality
5.Rapid starts
| Diesel generator KDE3500E | ||
| Model | KDE3500E | |
| Frequency (Hz) | 50 | |
| Output power (KVA) | 2.8 | |
| Max. Power(KVA) | 3 | |
| Voltage (V) | 115/230 | |
| Current (A) | 24.4/12.2 | |
| Engine speed (r/min) | 3000 | |
| Phase | Single | |
| Power factor(cosφ) | 1 | |
| Excitation system | Self-excited constant voltage | |
| Noise level (7m) | DB (A): 77 | |
| Fuel tank capacity (L) | 12.5 | |
| Structure | Open-frame | |
| Panel | Ordinary | |
| Outputsocket | Two | |
| Output terminal post | No | |
| DC12V output | Terminal post | |
| Engine Model | KA178F | |
| Bore*stroke (mm) | 78 *62 | |
| Displacement (L) | 0.296 | |
| Power (KW) | 3.68/3000 | |
| Fuel consumption rate (g. KW/h) | 276.1 | |
| Compression ratio | 20 | |
| Lubrication system | Spring | |
| Engine starting system | Electric starter | |
| Diesel oil model | Summer: 0#, winter: -10# | |
| Lube oil model | SAE10W-30 (above CD grade) | |
| Lube oil capacity (L) | 1.1 | |
| Battery capacity(V-AH) | 12V-36Ah | |
| Net weight (KG) | 70 | |
| Dimension(L*W*H) | 680×530×590 | |
