Low Price~Super Silent Diesel Generator

Name: Low Price~Super Silent Diesel Generator
Brand: Sumokama
SKU: 140760376
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Sumokama

Model Number:

KDE6700T-A

Changzhou Yarmax Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Sumokama

Model Number KDE6700T-A

Output Type AC Single Phase

Speed 3000/3600

Frequency 50HZ/60HZ

Rated Power 4.5/5

Rated Voltage 115/230-120/240

Rated Current 39.1/19.6-41.7/20.8

Specifications

Silent Diesel Generator
Model: KDE6700T-A
5Kw output power
Quite and Reliable

Model		KDE6700T-A
Frequency (HZ)		50	60
Rated Output (KVA)		4.5	5
Maximum Output (KVA)		5	5.5
Rated Voltage (V)		115/230	120/240
Rated current (A)		39.1/19.6	41.7/20.8
Rated rotation speed (rpm)		3000	3600
Phase No.		Single phase
Power Factor		COS=1
Excitation Mode		Self-excitation, 2 pole and constant voltage (AVR)
DC Output		12V./8.3A ,Connection Pole Output
Structure Type		Soundproof
Noise Level (7m) dB(A)		72
Engine Model		KM186FA
Engine type		Single-Cylinder, Vertical, Four-Stroke, Direct Injection,Air Cooled Diesel
Bore × Stroke(mm)		86×72
Displacement (L)		0.418
Rated Power KW		5.7/3000	6.3/3600
Fuel comsumption Rate(g.kw/h)		275.1		281.5
Compression Ratio		19:1
Lubrication System		Pressure Splashed
Starting System		Electric Start with 30Ah MF battery
Fuel Type		0#(summer),-10#(winter), diesel
Lube Oil Brand		SAE10W30 (above CD Grade)
Lube Capacity (L)		1.65
Fuel Tank Capacity (L)		15
Continuous Running Time (hr)		9.5
Overall Dimension: LxWxH (mm)		955 x 560 x 780
Dry Weight (Kg)		170
Quantity in 20FT		72 Pcs
Optiomal Features:
ATS	Optional
Digital Panel	Optional
Remote control	Optional
We reserve the right to change specifications without notice
