Lovol Low Noise Generator Set
USD $3,000 - $8,000
/ Piece
1 Piece(Min.Order)
- 100 Piece / Pieces per Month
- Shanghai
- T/T L/C Credit Card PayPal
You May Like
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Lovol | Model Number: | KDE0103E |
Output Type: | AC Three Phase | Speed: | 1500 | Frequency: | 50 |
Rated Power: | 131kva | Rated Voltage: | 220/110V |
Product Description
Specifications
1) Original lovol engine and stamford2)Low noise diesel generator set
3)Rated power 131kva
Model | Prime Power | Standby Power | |||||||
KDE131E | 104.8KW/131KVA | 115.2KW/144.1KVA | |||||||
Power Output at Different Voltage | |||||||||
Voltage (V) | Frequency (Hz) | Phase | PF (cos) | Standby Current (A) | Prime Current (A) | Standby Power (KW/KVA) | Prime Power (KW/KVA) | ||
440/254 | 50 | 3 | 0.8 | 189.08 | 171.89 | 115.2/144.1 | 104.8/131 | ||
400/230 | 50 | 3 | 0.8 | 207.99 | 189.08 | 115.2/144.1 | 104.8/131 | ||
380/220 | 50 | 3 | 0.8 | 218.94 | 199.03 | 115.2/144.1 | 104.8/131 | ||
220/127 | 50 | 3 | 0.8 | 378.17 | 343.79 | 115.2/144.1 | 104.8/131 | ||
Net Weight | 1720KG | ||||||||
Net Dimensions (Silent type) | 3000× 1050× 1750(MM) | ||||||||
GENERATOR | Rated Power | 104.8KW/131KVA | |||||||
Max. Power | 115.2KW/144.1KVA | ||||||||
Frequency | 50Hz | ||||||||
Rated Voltage | Optional | ||||||||
Power Factor | 0.8 | ||||||||
Phase | Three | ||||||||
Starting System | Electric | ||||||||
Noise Level(Dba/7M) | 80-85Db | ||||||||
Fuel Tank Capacity | 297L | ||||||||
Continues Runing Time | 24Hours | ||||||||
ENGINE | Brand / Model | LOVOL/1006TAG | |||||||
Model Information | Four Stroke, Liquid Cooled, Vertical Inline | ||||||||
Fuel System | Direct Injection Fuel System | ||||||||
No. of Cylinder | 6 - In Line | ||||||||
Bore× Stroke | 106× 127(mm) | ||||||||
Piston Displacement (L) | 5.98 | ||||||||
Firing Order | 1-5-3-6-2-6 | ||||||||
Compression Ratio | 17.5: 1 | ||||||||
Continuous Power/Speed (kW/rpm) | 121/1500 | ||||||||
Overload Power/Speed (kW/rpm) | 134/1500 | ||||||||
Governing rate (%) | ≤ 1% | ||||||||
Dimensions LxWxH (mm) | 1609x800x1064.2 | ||||||||
Weight, Dry (kg) (engine without packing) | 760 | ||||||||
Start Method | Electric Start | ||||||||
ALTERNATOR | Brand/ Type | Stanford | |||||||
Number of Phase | 3 | ||||||||
Connecting Method | 3 Phase and 4 Wires, “ Y” type connecting | ||||||||
Number of Bearing | 2 | ||||||||
Power Factor | 0.8 | ||||||||
Protection Grade | IP23 | ||||||||
Altitude Requirement | ≤ 1000m | ||||||||
Exciter Type | Brushless, Self-exciting | ||||||||
Insulation Class/Temperature Rise | H/H | ||||||||
Telephone Influence Factor (TIF) | < 50 | ||||||||
THF: | < 2% | ||||||||
Steady State Voltage Regulation | ≤ ± 1% | ||||||||
Alternator Capacity: | 131KVA | ||||||||
Alternator Efficiencies: | 90.30% | ||||||||
OPTIONAL | Engine: Water Jacket Heater / Water Separator | ||||||||
Alternator: Permanent Magnet Generator(PMG)/ Anti Condensation Heater | |||||||||
Control System: Auto Control Panel / ATS / Battery Charge | |||||||||
Others: Spare Parts / Tools / Daily Fuel Tank |
