HOT SALE!!! 10KW Air Cooled Diesel Generator Open Type KDE10E/KDE10E3

Model

KDE10E/KDE10E3

Rated frequency(Hz)

50

60

Rated Voltage(V)

230

230

Rated Current (A)

41.3

45.7

Rater Output (kW)

10

11

Max Output (kW)

11.5

12.5

Rated rotation speed(rpm)

3000  3600

Power factor

1

Phase number

Single/three

Excitation mode

Self-excitation and constant voltage (AVR)

Starting mode

Electrical start with start motor

DC output

12V 8.3A

Noise level dB(A)7m

79-85

Fuel tank capacity(L)

25

Continuous running time (hr)

8

Overall dimension(L*W*H)(mm)

1250*620*805

Dry weight(kg)

210

Engine model

KM290

Engine type

Two cylinder in-line,air-cooled,4-stroke,

direct injection, diesel engine

Bore*stroke(mm)

90x75

Total displacement (L)

0.954

Rated Power [kW(HP)/rpm]

13.5(18.3)/3000

14(19.0)/3600

Fuel type

0#(summer)-10#(winter)light diesel oil

Fuel consumption rate(g/kW.h)

270

290

Lube oil brand

LECD grade 15W40

Lubrication oil volume(L)

3.15

Compression ratio

19:1

Cooling system

Forced air-cooled
