Open Type Diesel Generator

Name: Open Type Diesel Generator
Brand: Sumokama
SKU: 140760160
Availability: InStock

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Sumokama

Model Number:

KDE2500E

Changzhou Yarmax Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Sumokama

Model Number KDE2500E

Output Type AC Single Phase

Speed 3000/3600

Frequency 50/60HZ

Rated Power 1.7/2.0

Rated Voltage 115/230 120/240

Rated Current 14.8/7.4 16.7/8.3

Specifications

Open Type Diesel Generator
Model: KDE2500E
2Kw output power
Reliable & long work life

Model	KDE2500E
Frequency (HZ)	50	60
Rated Output (KVA)	1.7	2.0
Maximum Output (KVA)	2.0	2.2
Rated Voltage (V)	115/230	120/240
Rated current (A)	14.8/7.4	16.7/8.3
Rated rotation speed (rpm)	3000	3600
Phase No.	Single phase
Power Factor	1.0
Excitation Mode	Self-excitation, 2 pole and constant voltage (AVR)
DC Output	12V./8.3A ,Terminal Post
Noise Level (7m) dB(A)	77
Engine Model	KM170FE
Engine type	Single-Cylinder, Vertical, Four-Stroke, Direct Injection, Air Cooled Diesel
Bore × Stroke(mm)	70 x 55
Displacement (L)	0.211
Rated Power KW	2.5/3000	2.8/3600
Fuel comsumption Rate(g.kw/h)	280.2	288.3
Compression Ratio	20:1
Lubrication System	Pressure Splashed
Starting System	Electric Start with 30Ah MF battery
Fuel Type	0#(summer)-10#(winter) diesel
Lube Oil Brand	SAE10W30 (above CD Grade)
Lube Capacity (L)	0.75
Fuel Tank Capacity (L)	12.5
Continuous Running Time (hr)	20
Overall Dimension: LxWxH (mm)	660 x 500 x 570
Dry Weight (Kg)	60
Quantity in 20FT	132 Pcs
Optiomal Features: Remote,ATS(Auto Transfer Switch) ,Digital Panel
We reserve the right to change specifications without notice
