10KW Air Cooled Diesel Generator

10KW Air Cooled Diesel Generator thumbnail-1
10KW Air Cooled Diesel Generator photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Sumokama
Model Number:
KDE12000E
Output Type:
AC Single Phase
Contact Supplier Request Quote Chat Now
Changzhou Yarmax Power Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Sumokama
Model Number KDE12000E
Output Type AC Single Phase
Speed 3000/3600
Frequency 50/60
Rated Power 10/11
Rated Voltage 230/240
Rated Current 43.5/45.8

Specifications

10KW Air Cooled Diesel Generator
Model: KDE1200E/1200E3
10Kw output power
Portable and Reliable

Model:KDE1200E

Rated frequency Hz:50/60

Rated output power kVA:10/11

Max. power kVA:11/12

Rated voltage V:230/240

Rated current A:43.5/45.8

Phase No.:single

Power factor (cosφ):0.9 (lag)

Insulation:F

Pole No.:2

Exciting mode:Brush, exciting-self voltage-constant (with AVR)

DC12V output:12V, 8.3A

Dimensions:L×W×H (mm):870×630×700

Net weight (Kg):195

Noise (7m)dB(A):82

Engine model:R2V840

Engine Type:V-twin, two-cylinder, four-stroke, Direct injection

Cylinder No. –bore ×stroke (mm): 2-86×72

Total displacement (ml):836

Compressed ratio:20:1

Cooling type:Air Cooled

Lubricating type:Pressure & splashing

Starting type:Electric Start

Fuel Type:0 # (summer) -10 # ( winter) -35 # (cold winter) light diesel

Oil Type:SAE10W30 (CD grade above)

SAE10W30 (CD grade above):1.7

Starting motor capacity V-kW:12V  1.4kW

Battery capacity V-Ah:12V  45AH

Fuel consumption under full loading (L/H):3.5/4.0

Fuel tank capacity ( L):25

Continuous running time  (Hr):7.1/6.5

Power factor (cosφ)
0.9 (lag)
