Rotary sand vibrating screen, concrete vibrating sieve machine price
1. Vibrating Screen Introduction:
With circular moving, circular vibrating screen is a kind of more layers and high efficiency new vibrating screen.
Adopting the tube body eccentric shaft vibration exciter and tilt block adjusting amplitude, it screens the materials
with longer line and more specifications. It has the advantages of reliable structure, strong vibrating force, high efficiency screening, lower noise, sturdy and durable, easy to maintain and safety operation, etc. It is widely used
to classify the materials in the areas or mine, building materials, communication, energy, chemical, etc.
2. Vibrating Screen Working Principle:
The vibrating screen consists of screen box, supporting device, vibration exciter, transmission part, etc. The motor
makes the exciter rotate speedily through the v-belt. The continuous forced circular motions of sieve box were
achieved through the powerful centrifugal force. Under the influence of sieve box, the materiel are tossed forward
successively on the mesh. They were classified as thrown up, and the particles smaller than the mesh size were
sieved out during the falling process, so that the classification of material could be achieved.
3. Vibrating Screen Features:
1. Exciter of external eccentric block structure has the advantages of big exciting force, light weight, small load
bearing, etc.
2. Novel structure, advanced technical parameters, high capacity, high screening efficiency, simple structure,
convenient sieve surface systems.
3.Adopting cross shaft transmission shaft or rubber universal section and flexible connection, so the operation is
very smooth.
4. Circle vibrating screen adapts the spring steel screen or punching screen panel, screen box shaking strong,
plugging holes is not ealisly blocked.
4. Vibrating Screen Technical Parameters:
Model | Layer | Dimension Size(mm) | Max.Feed Size(mm) | Capacity(t/h) | Vibrating Frequ Ency(r/min) | Power (kw) | Double Swing (mm) |
2YK1235 | 3 | 1200*3500 | 400 | 60-180 | 870 | 5.5 | 5-9 |
2YK1545 | 2 | 1500*4500 | 400 | 120-275 | 870 | 15 | 5-9 |
3YK1545 | 3 | 1500*4500 | 400 | 120-275 | 870 | 15 | 5-9 |
3YK1548 | 4 | 1500*4800 | 400 | 120-275 | 870 | 15 | 5-9 |
4YK1548 | 2 | 1500*4800 | 400 | 200-275 | 870 | 15 | 5-9 |
3YK1848 | 3 | 1800*4800 | 400 | 200-330 | 870 | 18.5 | 5-9 |
4YK1848 | 4 | 1800*4800 | 400 | 250-330 | 870 | 18.5 | 5-9 |
3YK1860 | 2 | 1800*6000 | 400 | 250-586 | 870 | 22 | 5-9 |
4YK1860 | 3 | 1800*6000 | 400 | 300-586 | 870 | 22-30 | 5-9 |
3YK2060 | 4 | 2000*6000 | 400 | 300-720 | 730 | 37 | 5-9 |
4YK2060 | 2 | 2000*6000 | 400 | 400-720 | 730 | 30-37 | 5-9 |
3YK2460 | 3 | 2400*6000 | 400 | 400-810 | 770 | 37 | 5-9 |
4YK2460 | 1 | 2400*6000 | 400 | 450-810 | 770 | 37 | 5-9 |
Packaging Detail:
All the cargos are packed by crate wood,other parts are nude package ,or as client demand.
Delivery Detail:
- If the size is suitable for container ship, usually by container;
- If the size is too big, usually by bulk ship or by container after truncation;
- Transport ways are based on reducing cost for you and keep the crane performance!
Zhengzhou Huahong Machinery to be the leading enterprise which is professional manufacture
double roller crusher,grading crusher, double teeth roller crusher ,our double roller crusher with
new design.We provide variety of double roller crusher with high processing capacity, featured
structure. As a specialized manufacurer and exporter in china, Zhengzhou Huahong striving its
best to service our customer.Our machines are all through ISO CE certificate. More details PLS
click on http://zzhuahong.en.china.cn/
1. Are you a trading company or a manufacturer?
We are a manufacturer.
2. How can I get to your company?
You can get a flight to Zhengzhou Xinzheng International Airport . and we can go to airport to pick
you up directly.
All our clients from home or abroad, are warmly welcome to visit our factory and inspect our products!
3. How long is your guarantee?
One year(Calculated from the equipment arrives the customer’s side.). After this period we will definitely support
you when needed. You will be welcome to contact us with any problem may happened.
4. Will you send engineers to install the plant?
yes, but at an extra cost payable by the customer. Or you can get local contractors to do the
commissioning and we send one supervising engineer.
- Sales manager cell number is 24hours available.
- Payment terms is flexible.
- Design the product according to your technical request.
- Our engineer is willing to help fixing the crane for you.
- Diversity products.
- Delivery on time.
- Warranty: 12 months.
- Trade Assurance Service.(Trade Assurance is a free payment protection service for buyers.
The service is offered by participating suppliers, and is designed to protect your payment if
your order is not shipped on time, or if the pre-shipment product quality (optional) does not
match the terms agreed on your contract.
Your payment is protected up to 100% of an amount - agreed between you and the supplier - called the Trade Assurance Order Amount.)
I am Helen Li, always being on serve you.
We cherish every order from every customer.
