Fine Powder Rotary Vibration Screen/Powder Sieving Machine
- 500 Set / Sets per Month
- Qingdao Tian port
- T/T L/C D/P D/A Credit Card PayPal
- circular vibrating screen ,vibrating screen price ,mining vibrating screen
- China gold mining sieve machine rounding vibrating screen
- mini electric motor sand double deck vibrating screen
- China manufacturer for rotary vibrating screen machine
- Rotary Vibration Screen|Circular Vibrating Screen Machine
- 3 layers sand vibrating screen for coal sand
Product Details
Condition: | New | Type: | Circular | Application: | Ore |
Place of Origin: | Henan, China | Brand Name: | Huahong | Model Number: | YK |
Voltage: | 380V | Power(W): | 5.5kw | Dimension(L*W*H): | Choose |
Weight: | 3600KG | Certification: | SGS ISO CE | Warranty: | 12 Months |
After-sales Service Provided: | Overseas third-party support available |
Packaging Details
vibrating screen are packed by standard wooden case.
Product Description
Rotary Fine Powder Rotary Vibration Screen/Powder Sieving Machine
1. Vibrating Screen Introduction:
With circular moving, circular vibrating screen is a kind of more layers and high efficiency new vibrating screen.
Adopting the tube body eccentric shaft vibration exciter and tilt block adjusting amplitude, it screens the materials
with longer line and more specifications. It has the advantages of reliable structure, strong vibrating force, high efficiency screening, lower noise, sturdy and durable, easy to maintain and safety operation, etc. It is widely used
to classify the materials in the areas or mine, building materials, communication, energy, chemical, etc.
2. Vibrating Screen Working Principle:
The vibrating screen consists of screen box, supporting device, vibration exciter, transmission part, etc. The motor
makes the exciter rotate speedily through the v-belt. The continuous forced circular motions of sieve box were
achieved through the powerful centrifugal force. Under the influence of sieve box, the materiel are tossed forward
successively on the mesh. They were classified as thrown up, and the particles smaller than the mesh size were
sieved out during the falling process, so that the classification of material could be achieved.
3. Vibrating Screen Features:
1. Exciter of external eccentric block structure has the advantages of big exciting force, light weight, small load
bearing, etc.
2. Novel structure, advanced technical parameters, high capacity, high screening efficiency, simple structure,
convenient sieve surface systems.
3.Adopting cross shaft transmission shaft or rubber universal section and flexible connection, so the operation is
very smooth.
4. Circle vibrating screen adapts the spring steel screen or punching screen panel, screen box shaking strong,
plugging holes is not ealisly blocked.
4. Vibrating Screen Technical Parameters:
Model | Layer | Dimension Size(mm) | Max.Feed Size(mm) | Capacity(t/h) | Vibrating Frequ Ency(r/min) | Power (kw) | Double Swing (mm) |
2YK1235 | 3 | 1200*3500 | 400 | 60-180 | 870 | 5.5 | 5-9 |
2YK1545 | 2 | 1500*4500 | 400 | 120-275 | 870 | 15 | 5-9 |
3YK1545 | 3 | 1500*4500 | 400 | 120-275 | 870 | 15 | 5-9 |
3YK1548 | 4 | 1500*4800 | 400 | 120-275 | 870 | 15 | 5-9 |
4YK1548 | 2 | 1500*4800 | 400 | 200-275 | 870 | 15 | 5-9 |
3YK1848 | 3 | 1800*4800 | 400 | 200-330 | 870 | 18.5 | 5-9 |
4YK1848 | 4 | 1800*4800 | 400 | 250-330 | 870 | 18.5 | 5-9 |
3YK1860 | 2 | 1800*6000 | 400 | 250-586 | 870 | 22 | 5-9 |
4YK1860 | 3 | 1800*6000 | 400 | 300-586 | 870 | 22-30 | 5-9 |
3YK2060 | 4 | 2000*6000 | 400 | 300-720 | 730 | 37 | 5-9 |
4YK2060 | 2 | 2000*6000 | 400 | 400-720 | 730 | 30-37 | 5-9 |
3YK2460 | 3 | 2400*6000 | 400 | 400-810 | 770 | 37 | 5-9 |
4YK2460 | 1 | 2400*6000 | 400 | 450-810 | 770 | 37 | 5-9 |
Packaging Detail:
All the cargos are packed by crate wood,other parts are nude package ,or as client demand.
Delivery Detail:
- If the size is suitable for container ship, usually by container;
- If the size is too big, usually by bulk ship or by container after truncation;
- Transport ways are based on reducing cost for you and keep the crane performance!
