Specifications
Electro drum wet magnetic separator for sale:1.For dry,wet separating
2.High magnetic intensity
3.Fine beneficiating results
2014 Electro drum wet magnetic separator for sale
Why do customers choose Huahong?
Features:
1. Short magnetic circuit;
2. Little magnetic flux leakage;
3. High magnetic intensity;
4. Low energy consumption;
5. Fine beneficiating results;
6. Simple structure and easy to maintain.
Huahong magnetic separator's main function:
1. Rough separating after coarse crushing in low-iron mine to reduce load.
2. In hematite reduction, detect the unchanged raw ore and return it to roasting.
3. Remove iron purity in ceramic mud to increase china quality.
4. Remove iron in coal mine, refractory production and casting sand.
Huahong magnetic separator's working principle:
1. When slurry flows into trough across ore-feeding tank, loose ore particles enter then trough's
ore-feeding zone under waterflow of ore-feeding hosepipe.
2. Upon magnetic field effect, magnetic particles get together and form into " magnetic mass" or
"magnetic linkage", which is absorbed to the cylinder under magnetic forece when it moves toward
magnetic pole.
3. Because the polarity of magnetic pole is alternatedly disposed along the cylinder's rotation direction
and remains unchanged at work, gangue and other non-magnetic minerals among "magnetic mass"
or "magnetic linkage" fall off when the cylinder rotates.
4. Then the "magnetic mass" or "magnetic linkage" absorbed to the cylinder surface comes out
as ore concentrate.
Magnetic separators in factory
5. Then the ore concentrate is unloaded into concentrate trough under under waterflow of ore
-unloading hosepipe, when it moves to the marginal magnetic system with lowest magnetic force
along the cylinder rotation.
6. And non-magnetic or weak magnetic minerals left in the slurry is discharged out of trough, which
is called gangue.
Huahong magnetic separator's technical parameters:
Model |
Magnetic strength(oe) |
Capacity(t/h) |
Power(kw) |
Weight(kg) |
CTB600*900 |
1450 |
8-15 |
1.1 |
910 |
CTB600*1800 |
1500 |
15-25 |
2.2 |
1340 |
CTB750*1800 |
1550 |
30-45 |
3 |
2050 |
CTB900*1800 |
1650 |
35-60 |
4 |
3000 |
CTB1050*2400 |
1650 |
60-95 |
5.5 |
5020 |
CTB1200*3000 |
1650 |
80-150 |
7.5 |
7800 |
CTB1500*3000 |
1650 |
120-200 |
11 |
9600 |
Real working sites of magnetic separator
Comfirmations:
In order to find the best suitable models and design of stone crusher plant for you,
kindly please inform us the following informations:
1. Which kind of material you're going to crusher? (Soft stone or hard sotne)
2. What's the max input size of raw matrial? (In inch, centimeter or millimeter)
3. What's the granularity of the final products you need? (In milimeter,micron or mesh)
4. What's the production capacity per hour you want?
5. Do you need just one jaw crusher or a complete crushing production line?
Welcome to visit our factory!
We will provide you our best equipments at the
reasonable price to meet your requirements.
