Help CenterCopper Ore Lead Zinc Flotation Machine Separator in Upgrading Unit
Related Products
-
Copper Ore Beneficiation Plant Use Flotation Separator Flotation MachineUS$ 1 - 10,000MOQ: 1 Set -
Industrial Lead Zinc Ore Flotation Machine Manufacturer of ChinaUS$ 1,000 - 99,999MOQ: 1 Set
-
2014 Copper Processing PlantUS$ 1,000 - 99,999MOQ: 1 Set
-
2016 New Benefication Alluvial Gold Processing PlantUS$ 1,000 - 99,999MOQ: 1 Set
-
Flotation Machine, Mineral Separating Machine for Copper Zinc Iron CoalUS$ 2,000 - 7,000MOQ: 1 Set
Specifications
1.Large inspiratory volume
2.Professional design
3.High recovery rate
4.Reliable quality
5.Good after sale service
Copper Ore flotation separator/froth flotation machine
Features of flotation machine:
1.High recovery ratoe
2.Every cell has three functions:disposition,slurry absorption,flotation separation
3.The strade can be changed
4.Strade contral the stablization of liquid level
Application of flotation machine:
Flotation cell machine is applicable for separating non-ferrous metal, black metal, noble metal, non-metal mineral, raw body and materials of chemical industry, which are subject to coarse separation, swept separation, fine separation and floatation, so the useful ore are reclaimed.
Introduction of flotation machine:
Flotation Machine must be levelly installed. Flotation Machine is easy to change the flow chart. The cycling way of magma is very reasonable. Flotation Machine can reduce the impurities to a great extent. There is automatic equipment on the magma surface, easy to adjust. The impeller also owns the upper and lower retroversion blade. The upper one makes the magma cycle upward, while the lower one makes the magma cycle downward.
When flotation machine works, slurry is inhaled from the bottom of the trough to the space between impellers. Meanwhile, the low pressure air send by fan is sent to this area through the air distributor in the hollow shaft. After sufficient mixing, the slurry is pushed out by the impeller, and then goes to the whole trough. When the froth rises to the stable level, after the enrichment processing, froth overflows to the froth trough from the overflow weir. Another part of ore slurry flows to lower part of impeller for the re-mix with air. The remained slurry flows to the next trough until becomes residue.
Parameters of flotation mahine:
Type |
Volume (m³) |
Capacity (m³/min) |
Diameter (mm) |
Speed (r/min) |
Weight of 4 cells (t) |
SF-0.37 |
0.37 |
0.2-0.4 |
300 |
352-442 |
1.0 |
SF-0.7 |
0.7 |
0.3-1.0 |
350 |
336 |
1.9 |
SF-1.2 |
1.2 |
0.6-1.6 |
450 |
298 |
2.8 |
SF-2.8 |
2.8 |
1.5-3.5 |
550 |
268 |
4.2 |
SF-4 |
4 |
2-4 |
650 |
305 |
5.2 |
SF-8 |
8 |
4-8 |
760 |
191 |
8.3 |
SF-10 |
10 |
5-10 |
760 |
191 |
9.0 |
Flotation machine features :
1.Simple structure & easy maintenance
2.All our products are on sale at a reasonable price
3.There are some working site near our factory, welcome you to our factory
