Small Scale Stone Crusher ,jaw Crusher Price Factory

Small Scale Stone Crusher ,jaw Crusher Price Factory thumbnail-1
Small Scale Stone Crusher ,jaw Crusher Price Factory thumbnail-2
Small Scale Stone Crusher ,jaw Crusher Price Factory thumbnail-3
Small Scale Stone Crusher ,jaw Crusher Price Factory thumbnail-4
Small Scale Stone Crusher ,jaw Crusher Price Factory thumbnail-5
Small Scale Stone Crusher ,jaw Crusher Price Factory thumbnail-6
Small Scale Stone Crusher ,jaw Crusher Price Factory photo-1
Small Scale Stone Crusher ,jaw Crusher Price Factory photo-2
Small Scale Stone Crusher ,jaw Crusher Price Factory photo-3
Small Scale Stone Crusher ,jaw Crusher Price Factory photo-4
Small Scale Stone Crusher ,jaw Crusher Price Factory photo-5
Small Scale Stone Crusher ,jaw Crusher Price Factory photo-6
US$ 1,000 - 9,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Jaw Crusher
Application:
stone, ore,rock
Contact Supplier Request Quote Chat Now
Zhengzhou Huahong Machinery Equipment Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai tianjing qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Jaw Crusher
Application stone, ore,rock
Motor Type AC Motor
Power(W) 55kw
Capacity(t/h) 60-100
Place of Origin Henan, China
Brand Name huahong
Model Number PE-500*750
Dimension(L*W*H) 1980 *2080*1870
Weight 12t
Certification ISO CE SGS GOST
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas


Advantages of the jaw crusher

1.The bearings adopt complete steel structure.
The whole cast steel housing can fully coordinate with the rack. Meanwhile, it greatly enhances the radial intensity of the bearings.

2.The applications of finite element analysis technology can greatly strengthen the efficiency of crushing process.

3. It is more convenient to adjust the discharging mouth.
The adjusting device is equipped with wedge block, while our devices are simpler and safer than the old-fashioned ones.



Working Principle of jaw crusher

The strip and strip pulley are driven by a motor, and the movable jaw moves up and down via eccentric shaft. The angle between fixed jaw and movable jaw becomes smaller when the movable jaw runs down, then the materials are crushed into pieces. It will become bigger when the movable jaw runs up. The movable jaw board leaves the fixed jaw board under the action of pole and spring ,then the end products come out from the crushing cavity.

English standard technical parameters:



Jaw crusher size

Tons/Hour

Feed Size

Discharge Size

Electric Hp

Weight(lbs)

5’’*6’’

0.5-1.5

4’’

3/8’’-1.5

5

750

6’’*10’’

1-3

5.5’’

1/2’’-2’’

7.5

1,600

8’’*12’’

2-6

7’’

3/4-2.5’’

10

2,400

10’’*16’’

5-20

9’’

3/4-3.5’’

20

5,600

16*24’’

15-60

14’’

1’’-3.5’’

45

14,000

20*30’’

40-110

18’’

1’’-4’’

75

24,000

24*30’’

50-180

22’’

1’’-4’’

75

32,000

24*36’’

80-240

22’’

2’’-6’’

75

34,000





 Product dates



Model Feed opening
size
(mm)		 Max
feed
size(mm)		 Adjustable
range
(mm)		 Capacity
(t/h)		 Eccentric shaft
rotary speed
(r/min)		 Motor
power
(kw)		 Total weight
(t)		 Overall dimensions
(L*W*H)(mm)
PE-150×250 150×250 125 10-40 1-3 250 5.5 0.8 720×660×850
PE-200×300 200×300 180 15-50 2-6 260 7.5 1.2 910×750×990
PE-200×350 200×350 180 18-70 3-10 260 11 1.5 1000×870×990
PE-250×400 250×400 210 20-60 5-20 300 15 2.8 1300×1090×1270
PE-400×600 400×600 340 40-100 16-60 275 30 7 1730×1730×1630
PE-500×750 500×750 425 50-100 40-110 275 55 12 1980×2080×1870
PE-600×750 600×750 500 150-200 80-240 275 55 15.8 2070×2000×1920
PE-600×900 600×900 500 65-160 50-180 250 55 17 2190×2206×2300
PE-750×1060 750×1060 630 80-140 110-320 250 90-110 29 2660×2430×2800
PE-800×1060 800×1060 640 160-220 130-330 250 110 29.8 2710×2430×2800
PE-830×1060 830×1060 650 160-220 150-336 250 110 30.7 2740×2430×2800
PE-870×1060 870×1060 660 200-260 190-336 250 110 31.5 2810×2430×2800
PE-900×1060 900×1060 685 230-290 230-390 250 110 33 2870×2420×2940
PE-900×1200 900×1200 750 95-165 220-450 200 110 52 3380×2870×3330
PE-1000×1200 1000×1200 850 195-265 315-500 200 110 55 3480×2876×3330
PE-1200×1500 1200×1500 1020 150-300 400-800 180 160 100.9 4200×3300×3500
PEX-150×750 150×750 120 18-48 8-25 320 15 3.8 1200×1530×1060
PEX-250×750 250×750 210 25-60 13-35 330 30 5.5 1380×1750×1540
PEX-250×1000 250×1000 210 25-60 16-52 330 30 7 1560×1950×1390
PEX-250×1200 250×1200 210 25-60 20-61 330 37 9.7 2140×1660×1500
PEX-300×1300 300×1300 250 20-90 16-105 300 55 15.6 2720×1950×1600

 small scale stone crusher ,jaw crusher price factorysmall scale stone crusher ,jaw crusher price factorysmall scale stone crusher ,jaw crusher price factorysmall scale stone crusher ,jaw crusher price factorysmall scale stone crusher ,jaw crusher price factorysmall scale stone crusher ,jaw crusher price factorysmall scale stone crusher ,jaw crusher price factorysmall scale stone crusher ,jaw crusher price factory

 small scale stone crusher ,jaw crusher price factory
