Specifications
1.High reliability2.Easy to operation
3.One year warranty
4.Flexible sttering
5.High effeciency
Widely used 12 ton hydraulic vibratory road roller with good quality
1. Features of QLND212H
1.Power system: cummins B-series extra-pressure diesel engine,huge power man coeffciency ,suitable for the operating conditon above 4000 meters altitude.
2.Total hydraulic pressure,total drive, frequency and radiation conversion, articulated direction change, two stepless speed changes, advanced technology, blocking the oil supply to brake the vehicle,safe and reliable.
3.Streamline outline,circular windshield glass and curvy hood form a unique style.
4.Hydraulic pump and vibrating motors are of the 90 series made by the american manufacturer SAUER.
5.Equipped with padfoot or removal padfoot as option
2. Standard configuration of QLND212H
Engine : 6BT5.9
Cab : Air conditioner cab
Travelling and vibrating system : Adopt the products of SAUER or REXROT
3. Optional configuration of QLND212H
1. Degree of compaction random detector
2. padfoot or removal padfoot
4. Main Technical Parameters of QLND212H
| Model | QLND212H | |
| Operating mass | kg | 12000 |
| Static linear load | N/cm | 342 |
| vibration amplitude | mm | 1.8/0.9 |
| Vibration frequency | Hz | 29/35 |
| Centrifugal force | KN | 260/160 |
| Travel speed | km/h | 12 |
| Grade ability | % | 35 |
| Turning radius | mm | 7000 |
| Overall dimension | mm | 5630x2260x3000 |
| Vibration round with | mm | 2100 |
| Wheelbase | mm | 3160 |
| Ground clearance | mm | 472 |
| Diesel power | KW | 110 |
| Diesel model | 6BT5.9 |
5. Application of QLND212H
QLND212H
Hydraulic vibratory roller is manufactured according to the international advanced technology
and by use of imported components from abroad.
The machine is super heavy-scale mechanized construction.
This machine is suitable for non-cohesive materials, such as graves, macadam,
macadam-aggregate mixtures and sandy soil etc.
Also it can be a good effect compaction in cohesive material.
Therefore the machine an ideal equipment for expressway,mining road, embankment, seaport and industrial sites.
6. Pictures of QLND212H
Details of QLND212H
Other choices
Our certificates
We offer low price products with highest performance cost ratio.
If you are interested in our road roller, please feel free to contact us.
Electronic catalog will be sent to you upon receipt of your inquiries.
Contact : Jenny lu
Skype: jenny.lv7
Tele: 0086-0371-55051327
Website:
Welcome to contact with us, and best service is our promise.
