21/25 Ton Heavy-duty Static Three Wheel Road Roller

21/25 Ton Heavy-duty Static Three Wheel Road Roller thumbnail-1
21/25 Ton Heavy-duty Static Three Wheel Road Roller photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, three tyre road roller
Static Linear Pressure:
front:575/650 N/cm rear:120/1358 N/cm
Contact Supplier Request Quote Chat Now
Henan Qianli Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, three tyre road roller
Static Linear Pressure front:575/650 N/cm rear:120/1358 N/cm
Travel Speed 2.0/4.0/9.6 km/h
Grade Ability 30%
Place of Origin Henan, China
Brand Name QLN
Model Number QLNJ2125
Power(W) 88kw
Dimension(L*W*H) 5700*2300*3000 mm
Weight 21000/25000 kg
Certification CE; ISO9001-2008
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.CE certificate
2.One year warranty
3.Spare part services
4.High dependable
5.High effencicy

21/25 ton heavy-duty static three wheel road roller with one year warranty 21/25 ton heavy-duty static three wheel road roller







1----Features of QLNJ2125 road roller



1.Steady quality,serial products coverwide applications.

2.Electric power sprinkler device.

3.Low gravity center,good stability.

4.Spacious and comfortable cab,with broad visual view.

5.Central articulated hydraulic steering for flexible turning and concenient operation.



2----Standard  configuration

Model : QLNJ2125

Engine : YC6108G

1.Static grinding,articulated short the body structure,cab mid-engine,working in a great view;
2.Hydraulic steering,low gravity toward the steering wheel deft and flexible;
3.Bridge type driving,hydraulic booster embedded disk brake,brake good,the two sets of brake system, safe and reliable;
4.Cab adopt glass that  against ultraviolet ray;
5.Equipped with large capacity and dynamic sprinkler system

3----Main Technical Parameters

MODEL   QLNJ2125
Operating mass     Overall length mm 5700
Without ballast kg 21000 Overall width mm 2300
With ballast   25000 Overall height mm 3000
Front linear load     Front wheel size mm
Without ballast N/cm 575 Width   1680
With ballast   650 Diameter   1500
Rear linear load   1200 Rear wheel size mm
Without ballast N/cm 1358 Width   530
With ballast     Diameter   1700
Travel speed     Wheelbase mm 2945
1st gear Km/h 2.0 Ground clearance mm 370
2nd gear   4.0 Diesel model   YC6B120
3rd gear   9.6 Diesel power Kw 88
Grade ability % 30 Diesel speed r/min 2000
Turning radius mm   Fuel tank capacity L 200
Inside   5180 Elecrical voltage V 24
Outside   7500 Hydraulic tank capacity L 40
Steering angle   ±35





4----Suitable environment

LTJ2125 The machines are heavy-duty static three wheel road rollers.With their dead weight, they compact cohesive and non-cohesive materials, such as gravel, sand stone mixture, sandy soil, and asphalt concrete.They are universal compaction equipments for highway, municipal road, parking area and industry ground etc, medium and large-scale construction projects.



5----Pictures of road roller

21/25 ton heavy-duty static three wheel road roller

21/25 ton heavy-duty static three wheel road roller



More details

 21/25 ton heavy-duty static three wheel road roller

 21/25 ton heavy-duty static three wheel road roller21/25 ton heavy-duty static three wheel road roller21/25 ton heavy-duty static three wheel road roller21/25 ton heavy-duty static three wheel road roller

 our certificates

21/25 ton heavy-duty static three wheel road roller21/25 ton heavy-duty static three wheel road roller



NOTE:



We offer low price products with highest performance cost ratio.



If you are interested in our road roller, please feel free to contact us.



 Electronic catalog will be sent to you upon receipt of your inquiries.





Contact : Jenny lu



Skype: jenny.lv7

Tele: 0086-0371-55051327

Website:





21/25 ton heavy-duty static three wheel road roller
