Specifications
1.With nice shape and compact struture2.Full-wheel drive
3.Strong climbing ability
4.Hydraulic teavel, adopt imported motor
Walking behind vibratory road roller,easy and useful road roller
1. Standard configuration of QLNC08H
1.Mechnical and full-wheel drive ,full-wheel vibration.
2.Engine: CF186F(changchai) Vertical DI air-cooled diesel engine.
3.Electric and manual starting devices system.
2. Main Features of QLNC08H
1.The whole machine has a nice shape,compact structure and small size;it can do rolling work in narrow ground;
2.All wheel drive,strong climbing ability.
3.Using CF186F vertical direct-spray air-cooled engine,with both electrical and manual startup devices;
4.Designed with guide wheel and joystick ,it is labor saving and easy to control.
5.Hydraulic travel,adopt imported pump&starting motor,CVT.
3. Main technical parameters of QLNC08H
| Model | QLNC08H | |
| Operating mass | kg | 770 |
| Static linear load | N/cm | 62/62 |
| Vibration amplitude | mm | 0.25 |
| Vibration frequency | Hz | 48 |
| Centrifugal force | KN | 12 |
| Travel speed | Km/h | 0-4 |
| Grade ability | % | 40 |
| Turning radius | mm | 2700 |
| Turning angle | ° | ±30 |
| Overall dimension | mm | 2400×880×1100 |
| Vibration drum diameter | mm | 400 |
| Vibration round width | mm | 600 |
| Wheelbase | mm | 470 |
| Diesel power | kw | 5.68 |
| Diesel model | CF186F | |
| rated speed | r/min | 2600 |
| diameter X travel | mm | 86x70 |
| discharge volume | mL/r | 10 |
| drum thinck | mm | 13 |
| drum width | mm | 60 |
| drum dirmeter | mm | 40 |
| fuel oil capacity | L | 5.5 |
| water capacity | L | 32 |
| hydraulic oil capacity | L | 10 |
| fuel consumption | 2K-100 |
4. Usage
QLNC08H Hydraulic walking behind vibratory road roller
can be used for municipal road construction,highway maintenance,and rolling work at narrow road surface,
such as foundation of groove wider than 0.8m, building construction, backfilling for pipeline and stadium ground.
5. Pictures showing
General view
Details:
Our assembly line
Our certificate
Note: We offer low price products with highest performance cost ratio.
If you are interested in our procudts, pls feel free to contact us.
Best service is our promise.
