60HP QLN function of four iron wheel tractor famous chinese cheap tractor

Specifications

High agricultural adaptability
Famous engine such like YTO
Reinforced PTO, hi-reliability
Famous chinese cheap tractor



QLN 50-65HP

HIGH QUALITY AGRICULTURAL TRACTORS



55 SERIES QLN TRACTOR (50-65HP)

QLN 50-65HP Series have both 2WD AND 4WD type tractor for dry and paddy field and for transportation. It can be used for various farm working with many implements, such as plough, harrow, harvest machine, flail mower and trailer etc.





1. CE and ISO certificate

2. Four-wheel-drive, a well sealed from drive axle

3. Non-maintenance of battery

4. Equipped with famous engine, lower oil consumption, high torque reservoir, excellent starting

5. Excellent working with draft control lever and position control lever, hydraulic steering system.

6. ROPS, canopy, enclosed cabin, multi-way hydraulic valve etc. can be chosen according to working request.



PRODUCTS:   QLN-604









1. High agricultural adaptability

2. Famous engine such like YTO/Lovol

3. Reinforced PTO, hi-reliability

4. Famous chinese cheap tractor





PARAMETER:

Model	QLN 604 (60HP)
Drive type	4×4
Technical parameter
Dimension(L×W×H)(mm)	3980×1635×2150
Wheel base (mm)	2150
Wheel tread F/R (mm)	1400/1300~1600
Adjust mothed of wheel tread	Level adjustment
Min. ground clearance (mm)	325
Engine
Engine type	Vertical ;water cooled ;             4-stroke ;direct injection
Brand	Quanchai ;YTO ; Yuchai
Volume of fuel tank (L)	43
Rated power (kW)	44
Rate oil consumption rate	≤2.04
Transmission
Clutch	Single,dry,dual-stage
Gear box	12F+12R
Speed of PTO (r/min)	540/760
Steering system
Steering system type	Hydraulic steering
Working device
Model of suspension mechanism	Rear mounted, 3-point linkage, categoryⅠ
Tilling depth control type	Floating control (separated)
Max. lifting force at suspension point 610 mm (kN)	≥10.0
PTO specification	Φ38×8 or Φ35×6 or Φ34.67×21



FARM EQUIPMENT:
