GPY300 HYDRAULIC BACKFILLER

Engine

model

CUMMINS 4BT3.9

Rated power

Kw

          75

Fuel consumption rate

g/kw.h

215

Chassis

Track width

mm

400

Track gauge

mm

2300

Length of track on ground

mm

2488

Walking device

Bidirectional guide wheel,Crawler butter up tight;Floating seal

Vibrating screen

Model

YA type round vibrating screen

Width

mm

1900

Length

mm

3200

Granularity of sieve mesh

mm

10

Conveyor

Total length

mm

5920

width of conveyor belt

mm

1000

Speed regulation mode

Manual step-less speed

Remote

Power

24VDC 5W

Control mode

FSK

Power supply

DC6V(5#battery,4sets)

Hydraulic system

Working supply

Triple gear pump

Motor

Cyclonic motor

Working valve

Solenoid directional valve

Rated pressure of system

Mpa

16

Production of soil and sand

M³

300

Working temperature of surrounding

℃

-25℃~+40℃

Suitable altitude

M

0-3600

Relative humidity

80%

Overall dimension(L*W*H)

working

M

8.72×5.82×3.35

shipping

5.26×3.85×3.15

Operating Weight

Kg

14000
