Help CenterYG48B MONANE PIPE CARRIER
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai/qingdao/tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Model Number
YG48B
YG48B MONANE PIPE CARRIER
Main Specification:
Model |
Unit |
YG48B |
Max carrying pipe diameter |
Inch/m |
48/1.219 |
Carrying device type |
|
Three axis swing arm type |
The max lifting angle of swimming arm |
° |
75° |
Max Grade Ability with full load |
° |
20° |
Max traveling speed |
Km/h |
Forward 6.6/reverse 7.8(Ⅱ) |
Engine model |
|
Cummins NTA885-C360 |
Rated power |
KW/rpm |
257/2000 |
Rated Pressure of system |
MPa |
20 |
Track Gauge |
mm |
2480 |
Length of track on ground |
mm |
3620 |
Track width |
mm |
760(860 optional) |
Tow winch |
|
Hydraulic driven,Planetary transmission |
Rated Pressure of system |
N |
196,000 |
Rope diameter |
mm |
Φ22 |
Temperature of surrounding |
℃ |
-30℃~+40℃ |
Overall diameter |
With swimming arm (m) |
6.0×6.0×3.71 |
When arm extended(m) |
6.0×9.1×3.71 |
|
Shipping (m) |
6.0×3.47×3.71 |
|
Ground Pressure |
Without load(Mpa) |
0.074 |
Operating weight |
kg |
42000 |
