Sales of X804 Four Wheel Tractor

Sales of X804 Four Wheel Tractor thumbnail-1
Sales of X804 Four Wheel Tractor photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Luoyang Mingyang Engineering Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai/tianjin/qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Lawn Tractor
Drive Type Other
Power(W) 59kw
Certificate CE
Brand Name YTO
Model Number X804
Place of Origin Henan, China
After-sales Service Provided Overseas service center available

                                                                                              YTO-X804

sales of X804 four Wheel Tractorsales of X804 four Wheel Tractorsales of X804 four Wheel Tractorsales of X804 four Wheel Tractorsales of X804 four Wheel Tractorsales of X804 four Wheel Tractor

The YTO-X804 tractor is developed on the basis of the Italian wheeled tractor chassis technology and adopts the British technology-based engine. The machine body has a streamline configuration. It has a low specific fuel consumption and a desirable power economic efficiency. It has multiple gears and a wide speed range. Besides, it is flexible in steering and easy to operate..



Model

YTO-X804

Tractor

Type

4×4

Overall dimensions(L×W×H)(mm)

4350×2170×2740

Wheelbase(mm)

2314

Min ground clearance(mm)

430

Min. operating mass(with safety stand)(kg)

3675

Tyre spec,front/rear

11.2-28/13.6-38

Wheel tread,front/rear

1569~1960/ 1500~2100

Steering

Full hydraulic

Brake

Oil immersed, disk type

Diesel engine

Model

LR4B5-23

Type

Four cylinder, vertical, water cooled, four stroke, direct injection combustion

Displacement(L)

4.95

Rated.power/speed (kw)(r/min)

58.8/2300

Max .torque(N.M)speed(r/min)

270/1500-1700

Bore ×stroke(mm)

108×125

Transmission

Gear shift,forward/backward

12/4

Speed range(km/h)forward/backward

1.63~26.82/

4.230~12.69

PTO power(kw)

50

PTO rotation speed(r/min)

540/720 or 540/1000

Clutch

11-inch,dry,double action

Implement

Three-point linkage category

Three-point linkage category II

Tilling depth control mode

Combined draft,position control and floating control

Lifting force(kn)

16

Options

OECD.anti-turnover bar

OECD certified anti-turnover bar or anti-turnover bar with awning

Transmission with shuttle-type gear

12+12

Transmission with creeper gear

24+8

Hydraulic output

2 or 3 group
