YTO 100hp Wheel Tractors YTO-X1004

YTO 100hp Wheel Tractors YTO-X1004 photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Tianjin Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Power(W) 74kw
Certificate CE
Brand Name YTO
Model Number YTO X1004
Place of Origin Henan, China
After-sales Service Provided Overseas service center available

                                                      Dongfanghong-x1004 wheel tractor



YTO 100hp wheel tractors YTO-X1004



YTO 100hp wheel tractors YTO-X1004YTO 100hp wheel tractors YTO-X1004YTO 100hp wheel tractors YTO-X1004



Employ original electronic control Perkins engine, high torque, powerful overload performance, low fuel consumption;
Absorb the design features of Italian mechanical T/M of the same power range, with rational layout structure;
Independent oil loop, hydraulic steering system control; safe and reliable wet or disc brakes for rear axle;
Brand new flat floor cab, elegant and comfortable, options: with cold or warm air or A/C;
Two independent PTO output speeds,540 and 1000 rpm, adaptable for all operation requirements;
High lifting force, with multiple tilling depth control;
Two groups of hydraulic output valves optioned with 3-group hydraulic valves..



Engine

Model



LR4A3L-23

Rated rotation speed

r/min

2400

Transmission system

Speed range forward

km/h

2.24-29.30

Speed range reverse

km/h

4.83-13.67

Machine body

Wheel base

mm

2648.5

Front wheel tread

mm

1760-2000

Rear wheel tread

mm

1600-2200

Min. turning radius

m

4.5

Max. operating weight

kg

5420

Specific fuel consumption under rated conditions

g/kW.h

≤245

Wheel tires (front / rear)



14.9-24/16.9-38

PTO shaft type



Rear-positioned, independent and synchronous

PTO shaft rotation speed

r/min

540/1000

Overall dimensions (L×W×H)

mm

5200X2696X2970

Min. ground clearance

mm

470
