Adopt Xin Chai Four Cylinder Diesel Engine.
Hydrodynamic transmission technology and separated structure make high reliability and easy maintenance.
Controlled by flexible shaft, hydraulic power shift gearbox with 2 forward and 2 reverse gears makes operate easy.
Single pump, split flow working hydraulic system makes lower consumption and excellent performance.
Load sensing fully hydraulic steering system makes operation easy.
Air over hydraulic brake system; Caliper disc brakes.
Working device with automatically leveling ability at high position.
Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability.
Integral, luxury instrument board.
New, luxury cabin.
Item | Specifications | Item | Specification |
Bucket Capacity | 0.5 m3 | Min. Turning Radius (outside of rear wheel) | 5000mm |
Rated Load | 1000 kg | Steering Angle | 35º left and right each direction |
Dumping Height | 2650 mm | Min. Ground Clearance | 250mm |
Dumping Reach | 855 mm | Wheel Base | 1900mm |
Boom Lifting Time | 3.6 s | Wheel Tread | 1400mm |
Max. Speed | 17km/h | Rated power | 36.8kw/2400rpm |
Max. Breakout Force | 34 kn | Tyre | 12-16.5 |
Max. Drawing Force | 30 kn | Overall Dimensions(L*W*H) | 5290*1680*2680mm |
Max. Gradeability | 25° | Operating weight | 3700kg |
