Hot Sale XCMG Asphalt Concrete Paver RP602
XCMG 6m Asphalt Concrete Paver RP602
Paving Width Ranges:2.5~6m
Max Paving Thickness:380mm
Engine: BF4M1013C
RP602/RP802 multi-functional paver can be applied to the paving of basic stabilized material and surface material. The machine adopts independent right drive and left drive, micro-computer control, and the telescopic screed with single vibrating tamper (RP802 is equipped with pulse vibration). The material level is controlled by ultrasonic sensing technique, featuring good stability in low-speed paving, even material feeding, high preloading compactness, good pavement evenness, and easy operation. It can absolutely meet the construction requirements.
Parameters
| Item | Unit | RP602 |
|---|---|---|
| Basic paving width | m | 2.5 |
| Max. paving width | m | 6 |
| Max. paving thickness | mm | 380 |
| Paving speed | m/min | 0~14 |
| Travel speed | km/h | 0~3.0 |
| Theoretical productivity | t/h | 400 |
| Hopper capacity | t | 13 |
| Gradeability | % | 20 |
| Pavement evenness | mm/3m | 3 |
| Cross slope error | % | ±0.03 |
| Crown adjustment range | % | 0~3 |
| Diesel engine model | BF4M1013C | |
| Diesel engine power | kw | 118 |
| Diesel engine speed | r/min | 2300 |
| Diesel oil tank capacity | L | 230 |
| Overall weight | t | 15.8~21.5 |
| Dimension | mm | 6230×2500×3855 |
| Vibration frequency | Hz | / |
| Screed heating mode | Electrical heating | |
| Material level control mode | Automatic Control by Ultrasonic Sensor | |
| Automatic Leveling Control | Simulation control |
| Item | Unit |
|---|---|
| Screed model | 475(RP602) |
| Type | Vibration, electrical heating |
| Stretch mode | Hydraulic stretch |
| Width range | 2.5-6.0m |
| Vibrating tamper rotate speed | 0-1500r/min |
| Vibration frequency | 4mm |
The warranty covers the Product, for one (1) year from the documented date of purchase.
We promise excellent service under the warranty:
1. We will send the new spare parts by air express, such as DHL or TNT once our customers request an urgent replace of broken parts under warranty
2. We will arrange engineers to service machinery overseas in case our customers are in need help for installation and training, such as tower cranes, concrete batching plant, asphalt mixing plant, stone crushing plant, etc.
3. We will send original spare parts by shipment or air express for option in case our clients want to purchase some other spare parts for repair and regular maintenance of their machines.
As a leading exporter specially for a big variety of construction equipment, Shanghai Dobest Construction Machinery Co., Ltd. is located in China's biggest port city Shanghai, which is also the financial center and business center.
Our mission is to provide a 'one-stop' service to fulfill our customers’ needs and expectations with the high quality product, prompt delivery and perfect service after sales. We promise to do our best to make our customers satisfied as we offer professional construction solutions for their kinds of projects.
By keeping the principle of good quality, competitive price, superior service, now we have won a very good reputation from all of our customers all over the world. Thus, our business expanded rapidly and so far we have exported our products to more than 20 countries and regions, including Australia, New Zealand, Brazil, Argentina, Honduras, Algeria, Tanzania, Kenya, Ethiopia, Djibouti, Congo, Morocco, UAE, Saudi Arabia, Iraq, Singapore, Thailand, Malaysia, Philippines and etc. Our market is mainly in Africa, South America, Middle East, South East Asia and some European countries.
We devote ourselves to provide a wide range of Chinese well-known construction equipment series to fulfill our customer’s different demands for their projects.
