Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Excavator > CE Big Backhoe Fitted With Tractor PTO With Three Point Linkage ,with Self Gearbox
CE Big Backhoe Fitted With Tractor PTO With Three Point Linkage ,with Self Gearbox
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
HT-LW
Model Number:
TZ04,06,08,10
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mini Garden Tractor Backhoe LW-6,7,8,better Price &higher QualityNegotiableMOQ: 1 Set -
Tractor Backhoe by PTO With Three Point Linkage ,with GearboxNegotiableMOQ: 1 Set
-
Small Backhoe Fitted With Tractor PTO With Three Point Linkage With Self GearboxNegotiableMOQ: 1 Set
-
Promotional Compact Tractor Backhoe ,better Price &higher QualityNegotiableMOQ: 1 Set
-
Compact Tractor Backhoe by PTO With Three Point Linkage ,with GearboxNegotiableMOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
HT-LW
Model Number
TZ04,06,08,10
Condition
New
Specifications
This series backhoe can matched with DIFFERENT BRABD tractors and also DIFFERENT HP tractorSPECIFICATION OF BACKHOE
| Model | LW-6 | LW-7 | LW-8 |
| Maximum Digging Depth | 6'0" | 7'0" | 8'0" |
| A. Digging Depth (two foot flat bottom) | 5'6" | 6'6" | 7'6" |
| B. Swing Arc | 180 ° | 180 ° | 180 ° |
| C. Loading Height (bucket at 60 ° ) | 5'0" | 5'0" | 5'10" |
| D. Reach from Center Line of Swing Pivot | 8'6" | 8'6" | 9'6" |
| E. Transport Height (maximum) | 4'11" | 4'11" | 5'9" |
| F. Bucket Rotation | 180 ° | 180 ° | 180 ° |
| G. Loading Reach (bucket at 60 ° ) | 3'2" | 3'2" | 3'7" |
| H. Transport Overhang | 3'5" | 3'5" | 3'6" |
| I. Undercut | 2'4" | 2'4" | 2'6" |
| J. Stabilizer Spread, down position | 6'6" | 6'6" | 7'5" |
| K. Stabilizer Spread, up position | 3'11" | 3'11" | 5'1" |
| Bucket Cylinder Digging Force | 2450 lbs | 2450 lbs | 2840 lbs |
| Dipper stick Cylinder Digging Force | 1250 lbs | 1250 lbs | 2005 lbs |
| Shipping Weight (less bucket) | 586 lbs | 654 lbs | 875 lbs |
| Hydraulic Volume Requirements | 4 to 5 GPM | 4 to 5 GPM | 5 to 6 GPM |
| Hydraulic Pressure Requirements | 2250 psi | 2250 psi | 2250 psi |
| Recommended Tractor HP Requirements | 15 - 30 HP | 18 - 35 HP | 25 - 45 HP |
| Specifications May Very Depending on Tractor Model and Subject to Change Without Notification. | |||
| Tractor Must Be Equipped with ROPS and Seat belt That will Provide Better Safety. | |||
