BOMR FIAT Gearbox farm diesel tractor (904 Shuttle shift)

Specifications

1. 12+12 shuttle shift
2. Turbo charge
3. Italy fiat chassis
4. Increase 30% efficiency
5. Save 25% of fule



The characteristic of tractor from 70hp to 100hp

1. Our tractors have YTO or Quanchai engine; the engine has the strong power and high quality.
2. Gearbox has 12 forward shifts and 4 reverse shifts.
3. The side shift control made the shifting more comfortable and humanistic.
4. Gearbox and rear axle use engagement sleeve shift. Shifting flexibly and stably, never neutral
5. Hydraulic steering system has independent oil circuit.
6. Independent PTO shaft has so many speed of rotation to choose. For example, 540/760/850/1000. It can meet customer’s different requirements when using tractor in the farm.
7. Pedal operated hydraulic driving brake system and hand shank operated mechanical parking brake system, made the brake system is safety and reliable.
8. Force buried lifter (force, position comprehensive control and floating control) is using reliably and mending conveniently. Hydraulic system use oil separate structure, which has strong lifting capacity. It matches with many large agricultural implements.
9. 1 or 2 pair hydraulic outputs can be chose. And air-brake can be chose.

 10.   Use 4 planetary wheeled differential, transmission stably and reliably.

 11.   Our tractor adopt underneath double diesel tank. The diesel tank’s volume is large, which reaches 150L. And it is satisfied with using tractors for long-time.

 12.   Reinforced 3 point-suspension postposition is stronger, using reliable and long life. The bottom tie rod can float



The Main Specification of Bomr 90hp tractor
Tractor Model		BOMR900	BOMR904	BOMR950	BOMR954
General Specification	Driver Type	4×2	4×4	4×2	4×4
	Length×width×Height(mm)	4550×2050×2850	4520×2170×2530	4550×2050×2850	4520×2170×2530
	Traction force(KN)	17.7	19.8	18.7	20.9
	Steering	Hydraulic	Hydraulic	Hydraulic	Hydraulic
	Wheel base(mm)	2195	2314	2195	2314
	Front wheel tread(mm)	1385-1685	1562-2000	1385-1685	1562-2000
	Rear wheel tread(mm)	1608-1996	1520-2120	1608-1996	1520-2120
	P.T.O.Max.Power(Kw)	59.4	59.4	63	63
	Ground clearance(mm)	425	440	425	440
Engine	Type	YTO 90HP	YTO 90HP	YTO 95HP	YTO 95HP
	Bore×Stroke(mm)	112×135	110×135	115×135	105×125
	Rated revolution (r/min)	2300	2300	2300	2300
	Max.torque(n.m)	≥298	≥325	≥315	≥350
	Speed of Max.torque r.p.m.	1500-1700	1500-1700	1500-1700	1500-1700
Transmission	Clutch	Dual-stage clutch
	Gear box	12F+4R
Working device	Hydraulic lifter tilling depth control	Forced buried
	Max.lifting capacity(KN)	14.9	14.9	15.7	15.7
	Suspension type	Class 2  3-Point hitch
	Speed of P.T.O.(r/min)	stardard;540/720;optional:540/1000,720/1000
Notice:All above parameters are subject to change without notice because of rapid development of products.
