BOMR FIAT Gearbox Diesel Farm Tractor (904 Air Brake)

BOMR FIAT Gearbox Diesel Farm Tractor (904 Air Brake) thumbnail-1
BOMR FIAT Gearbox Diesel Farm Tractor (904 Air Brake) photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Luoyang Boma Agricultural Engineering Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Certificate EPA
Brand Name BOMR
Model Number BOMR 904
Place of Origin Henan, China

Specifications

1. 12+12 shuttle shift
2. Turbo charge
3. Italy fiat chassis
4. Increase 30% efficiency
5. Save 25% of fule

BOMR FIAT Gearbox diesel farm tractor (904 Air brake)BOMR FIAT Gearbox diesel farm tractor (904 Air brake)BOMR FIAT Gearbox diesel farm tractor (904 Air brake)



BOMR FIAT Gearbox diesel farm tractor (904 Air brake)BOMR FIAT Gearbox diesel farm tractor (904 Air brake)BOMR FIAT Gearbox diesel farm tractor (904 Air brake)

The characteristic of tractor from 70hp to 100hp

  1. Our tractors have YTO or Quanchai engine; the engine has the strong power and high quality.
  2. Gearbox has 12 forward shifts and 4 reverse shifts.
  3. The side shift control made the shifting more comfortable and humanistic.
  4. Gearbox and rear axle use engagement sleeve shift. Shifting flexibly and stably, never neutral
  5. Hydraulic steering system has independent oil circuit.
  6. Independent PTO shaft has so many speed of rotation to choose. For example, 540/760/850/1000. It can meet customer’s different requirements when using tractor in the farm.
  7. Pedal operated hydraulic driving brake system and hand shank operated mechanical parking brake system, made the brake system is safety and reliable.
  8. Force buried lifter (force, position comprehensive control and floating control) is using reliably and mending conveniently. Hydraulic system use oil separate structure, which has strong lifting capacity. It matches with many large agricultural implements.
  9. 1 or 2 pair hydraulic outputs can be chose. And air-brake can be chose.

 10.   Use 4 planetary wheeled differential, transmission stably and reliably.

 11.   Our tractor adopt underneath double diesel tank. The diesel tank’s volume is large, which reaches 150L. And it is satisfied with using tractors for long-time.

 12.   Reinforced 3 point-suspension postposition is stronger, using reliable and long life. The bottom tie rod can float



The Main Specification of Bomr 90hp tractor
Tractor Model BOMR900 BOMR904 BOMR950 BOMR954
General Specification Driver Type 4×2 4×4 4×2 4×4
Length×width×Height(mm) 4550×2050×2850 4520×2170×2530 4550×2050×2850 4520×2170×2530
Traction force(KN) 17.7 19.8 18.7 20.9
Steering Hydraulic  Hydraulic  Hydraulic  Hydraulic
Wheel base(mm) 2195 2314 2195 2314
Front wheel tread(mm) 1385-1685 1562-2000 1385-1685 1562-2000
Rear wheel tread(mm) 1608-1996 1520-2120 1608-1996 1520-2120
P.T.O.Max.Power(Kw) 59.4 59.4 63 63
Ground clearance(mm) 425 440 425 440
Engine Type YTO 90HP  YTO 90HP YTO 95HP YTO 95HP
Bore×Stroke(mm) 112×135 110×135 115×135 105×125
Rated revolution (r/min) 2300 2300 2300 2300
Max.torque(n.m) ≥298 ≥325 ≥315 ≥350
Speed of Max.torque r.p.m. 1500-1700 1500-1700 1500-1700 1500-1700
Transmission Clutch Dual-stage clutch
Gear box 12F+4R
Working device Hydraulic lifter tilling depth control Forced buried
Max.lifting capacity(KN) 14.9 14.9 15.7 15.7
Suspension type Class 2  3-Point hitch
Speed of P.T.O.(r/min) stardard;540/720;optional:540/1000,720/1000
Notice:All above parameters are subject to change without notice because of rapid development of products.
