High Quality Placer Gold Mining Trommel Screen
1.Features:
- High Quality Placer Gold Mining Trommel Screen ;
- This gold mining plant can improve the recovery of the gold and reduce the workload of cleaning.;
- get gold with little impurity;
- Can do continuous process, advanced spiral system, increase gold recovery rate, reduce operator;
2. High Quality Placer Gold Mining Trommel Screen Specification:
NO | Item |
| Remark |
1 | Dimension | ||
| Length | 11.9m |
|
| Width | 2.3m |
|
| Height | 2.9m |
|
| Operating Weight | 15000kg |
|
2 | Wet-type hopper | L*W: 3.7m*2.4m |
|
3 | Trommel with washing function | Φ0.9m,L: 7.5m | With two washing room |
| Sieve pore | 6mm,8mm | Optional |
4 | Outside Drums
| Φ1.8m,L: 6m | 1/This section is the drum outside the trammel. 2/The section with screw is used for separating the gold from the sand |
| Speed governing method | Frequency converting control | This function can make the plant run at a low rate with efficiency such as 20tph for example. |
5 | Concentrate Sluice | L*W: 6m*0.3m |
|
| Efficient mats | 2sets* |
|
6 | Tailings Sluice | L*W: 6m*1m |
|
| Efficient mats | 2sets |
|
7 | Conveyer belt | Belt L*W: 9m*0.6m |
|
7 | Diesel water pump | DP6" |
|
| Flux/Pumping head | 200m³/30m |
|
8 | Generator set | Weichai 30kw |
|
| Diesel driving motor | 4100ZLD |
|
9 | Handling capacity | 100m³/h |
|
10 | Feed way | Excavator or wheel loader | |
11 | Loading | 1*40HQ |
|
Contact: Daisy
Phone No.: 86-15206300360
Skype: ji_meiyan
3. High Quality Placer Gold Mining Trommel Screen Details:
This washing-trommel screen has a washing room, can separate the rocks>10cm away.
There is PU lining in hopper and support wheel, which can prolong the using life of parts.
All the high quality placer gold mining trommel screen packed in nude. We can also provide many types of packaging to meet any special requirements.
| Model | Diamension | Quantity |
| SG-GM10 | 4.7*2.3*2.9m | 1*20'GP |
| SG-GM100 | 11.9*2.3*2.9m | 1840'GP |
Customer’s requirement is our first priority. We can provide reliable, fast and professional 24/7 service for you through telephone, on-site or network channels.
Regarding the warranty time, 12months, during the Guaranteed Period, service of guarantee will be supplied on condition that the machine or parts appear to have defects because of bad quality.
Regarding spare parts,we have enough ready stock for supply to our customers, which can guarantee to help them get parts and replace them on machines in shortest time.
Regarding technical support, we have professional engineer and technician to answer your question and doubt for machines and any problem you have during operation with machines.
Regarding logistic and shipping, we have long-term and trustworthy forwarder to supply you one-stop service.
SincerelyLooking forward to cooperate with you!
Contact: Daisy
Phone No.: 86-15206300360
Skype: ji_meiyan
