lifting height 38m telescopic boom
- 500 Set / Sets per Month
- shanghai
- T/T
- Caterpillar 439-5037 4395037 Fuel Water Separator Filter CAT EC200D EC170C/D Excavator
- 207 Engine Hydraulic Filter HF6710 AT58368 86542664
- 1 Ton Garden Excavator For Sale
- XY-2 Water Well Drilling Rig for Exploration and Core Drilling
- Y-44A Core Drilling Machine With Rope Retrieval For Geological Exploration, Kilometer Long Core Drilling Machine
- XY-44A1400m Rock Core Drilling Machine Engineering Geological Drilling Deep Rock Core Sampling Large Hydraulic Drilling Machine
Product Details
Place of Origin: | Shanghai, China | Brand Name: | GP | Model Number: | GTBZ38 |
Product Description
Specifications
Platform height max. 38.1MWorking height max. 40.1M
Horizontal reach max. 22.5M
Platform Load capacity250kg
1
Item | Measurement | Item | Measurement |
Dimensions | Productivity | ||
Overall length(stowed) | 14.02M (46ft) | Platform height max. | 38.1M (125ft) |
Overall width(stowed) | 2.49M (8ft) | Working height max. | 40.1M (132ft) |
Overall height(stowed) | 3.08M (10ft) | Horizontal reach max. | 22.5M (74ft) |
Ground clearance | 0.43M (1.4ft) | Turntable rotation | 360°continuous |
Wheelbase | 3.66M (12ft) | Platform rotation | 160° |
Overall weight | 20300kg (4WD) | Platform Load capacity | 250kg (non-restricted) |
Platform Size (L*W*H) | 1.83*0.76*1.1M (6ft *2.5ft *3.6ft) | Grade ability | 40% (4wd) |
Platform levelling | Automatic | Turning radius(outside) | 5.57M (18ft) |
Tire specification | 12.00-20 | Turning radius(inside) | 2.56M (8ft) |
Tire type | Solid | Turntable tailswing | 1.82M (6ft) |
Power | Max. Driving Speed | 4.4KM/H | |
Hydraulic tank vol. | 200L | Driving Speed (stowed) | 0~4.4km/h |
Hydraulic system vol. (inc. the tank) | 300L | Driving Speed (extended) | 0~1.1km/h |
Fuel tank vol. | 150L | Max allowable wind force | 12.5m/s |
Control voltage | 24V | Max allowable slope | 3° |
Engine | Original Cummins B3.3 80hp | Max noise on normal use | 82dB(A) |
Drive & steer model | 4WD*4WS | Max allowable side force | 400N |
