Help CenterLifting Height 40m Telescopic Boom
Related Products
Specifications
Platform height max. 39.28MWorking height max. 41.28M
Horizontal reach max. 24.38M
Platform Load capacity250kg
Item |
Measurement |
Item |
Measurement |
Dimensions |
Productivity |
||
Overall length(stowed) |
13.1M (40ft) |
Platform height max. |
39.28M (129ft) |
Overall width(stowed) |
2.49M (8ft) |
Working height max. |
41.28M (135ft) |
Overall height(stowed) |
3.05M (10ft) |
Horizontal reach max. |
24.38M (80ft) |
Ground clearance |
0.30M (1ft) |
Turntable rotation |
360°continuous |
Wheelbase |
3.81M (12.5ft) |
Platform rotation |
160° |
Overall weight |
21560kg (4WD) |
Platform Load capacity |
250kg (non-restricted) |
480kg (restricted) | |||
Platform Size (L*W*H) |
2.44*0.91*1.1M (8ft*3ft*3.6ft) |
Grade ability |
40% (4wd) |
Platform levelling |
Automatic |
Turning radius(outside) |
6.81M (23ft) |
Tire specification |
12.00-20 |
Turning radius(inside) |
4.37M (14.3ft) |
Tire type |
Solid |
Turntable tailswing |
1.65M (5.4ft) |
Power |
Max. Driving Speed |
5KM/H |
|
Hydraulic tank vol. |
250L |
Driving Speed (stowed) |
0~5km/h |
Hydraulic system vol. (inc. the tank) |
375L |
Driving Speed (extended) |
0~1.1km/h |
Fuel tank vol. |
200L |
Max allowable wind force |
12.5m/s |
Control voltage |
24V |
Max allowable slope |
3° |
Engine |
Perkins 1104D |
Max noise on normal use |
82dB(A) |
Drive & steer model |
4WD*4WS |
Max allowable side force |
400N |
