Help CenterLifting Height 36m Telescopic Boom
Related Products
Specifications
Platform height max. 36.5MWorking height max. 38.5M
Horizontal reach max. 22M
Platform Load capacity340kg
Item |
Measurement |
Item |
Measurement |
Dimensions |
Productivity |
||
Overall length(stowed) |
12.5M (41ft) |
Platform height max. |
36.5M (120ft) |
Overall width(stowed) |
2.49M (8ft) |
Working height max. |
38.5M (126ft) |
Overall height(stowed) |
3.08M (10ft) |
Horizontal reach max. |
22M (72ft) |
Ground clearance |
0.43M (1.4ft) |
Turntable rotation |
360°continuous |
Wheelbase |
3.66M (12ft) |
Platform rotation |
160° |
Overall weight |
20100kg (4WD) |
Platform Load capacity |
340kg (non-restricted) |
480kg (restricted) | |||
Platform Size (L*W*H) |
2.44*0.91*1.1M (8ft*3ft*3.6ft) |
Grade ability |
40% (4wd) |
Platform levelling |
Automatic |
Turning radius(outside) |
5.57M (18ft) |
Tire specification |
12.00-20 |
Turning radius(inside) |
2.56M (8ft) |
Tire type |
Solid |
Turntable tailswing |
1.82M (6ft) |
Power |
Max. Driving Speed |
4.4KM/H |
|
Hydraulic tank vol. |
200L |
Driving Speed (stowed) |
0~4.4km/h |
Hydraulic system vol. (inc. the tank) |
300L |
Driving Speed (extended) |
0~1.1km/h |
Fuel tank vol. |
150L |
Max allowable wind force |
12.5m/s |
Control voltage |
24V |
Max allowable slope |
3° |
Engine |
Original Cummins B3.3 80hp |
Max noise on normal use |
82dB(A) |
Drive & steer model |
4WD*4WS |
Max allowable side force |
400N |
