Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
GP
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Electric Stacker With Stand-on PlatformNegotiableMOQ: 1 Set -
1 Ton Hand Hydraulic Stacker SFH1016NegotiableMOQ: 1 Unit
-
1.0-2.0Ton Hand Hydraulic StackerNegotiableMOQ: 1 Unit
-
2Ton Semi-Electric Stacker Lift Height 1.6-3mNegotiableMOQ: 1 Unit
-
1.2-2.0 Ton Full Battery Stacker With American CURTIS Electric ControllerNegotiableMOQ: 1 Unit
Condition
New
Place of Origin
Shanghai, China
Brand Name
GP
Model Number
TA10T
Type
Powered Pallet Truck
Power Souce
AC Motor
Rated Loading Capacity
1000kg
Max. Lifting Height
3.5m
Min. Lifting Height
2m
Fork Length
1000mm
Fork Width
680mm
Overall Dimensions
1660*930*2080mm
Specifications
1)Stability Analysis of Structures, compacted design2)Strong frame, operating lightly and easil
1.Stability Analysis of Structures, compacted design Strong frame, operating lightly and easily
2.The import hydraulic pump rises and falls the pumping station, lifts is fast, is steady.
3.Manual travel and powered lift.
4.Heavy duty design with quality mast construction.
5. Delicate and durable steel plate fork,
6.Guarantee that use it safely for long time.
| Model | ||||||||||
| Specification | TA10T-20 | TA10T-25 | TA10T-30 | TA10T-35 | TA15T-20 | TA15T-25 | TA15T-30 | TA15T-35 | TA20T-20 | |
| Rate capacity | kg | 1000 | 1500 | 2000 | ||||||
| Load center | mm | 400 | ||||||||
| Max. fork height | mm | 2000 | 2500 | 3000 | 3500 | 2000 | 2500 | 3000 | 3500 | 2000 |
| Max.machine height | mm | 2560 | 3060 | 3560 | 4060 | 2560 | 3060 | 3560 | 4060 | 2560 |
| Fork length | mm | 1000 | ||||||||
| Fork width | mm | 300-680 | ||||||||
| Min.turning radius | mm | 1350 | 1450 | 1350 | 1450 | 1350 | ||||
| Wheel base | mm | 1185 | ||||||||
| Front- wheel distance | mm | 316 | ||||||||
| Lifting motor | v/kw | 12/1.5-1.6 | ||||||||
| Aneroid battery | v/Ah | 12/120-150 | ||||||||
| Charger | v/A | 12/15 | ||||||||
| Overall length | mm | 1660 | ||||||||
| Overall width | mm | 810 | 930 | 810 | 930 | 810 | ||||
| Overall height | mm | 1580 | 1830 | 2080 | 2330 | 1580 | 1830 | 2080 | 2330 | 1580 |
| Overall net weight | kg | 425 | 450 | 470 | 500 | 450 | 475 | 495 | 520 | 470 |
