2.5ton narrow legs AC powered electric pallet truck ERE225
Negotiable
/ Unit
1 Unit(Min.Order)
- 200 Set / Sets per Month
- Shanghai
- T/T
You May Like
Product Details
| Condition: | New | Place of Origin: | Shanghai, China | Brand Name: | GP |
| Model Number: | ERE225 | Type: | Powered Pallet Truck | Power Souce: | AC Motor |
| Rated Loading Capacity: | 2500kg | Max. Lifting Height: | 205mm | Min. Lifting Height: | 85mm |
| Fork Length: | 1150/1200mm | Fork Width: | 185mm |
Product Description
| Model | EJE/ERE220 - EJE/ERE225 | ||
| Feature | Load capacity | kg | 2000/2500 |
| Load center | mm | 600 | |
| Wheelbase | mm | 1480 | |
| Operating type | Walk/ Stand on | ||
| Wheels | Wheel type | PU | |
| Wheel quantity Driving/Balance/Bearing wheel | 1/2/4 | ||
| Driving wheel size | mm | Φ248×75 | |
| Balance wheel size | mm | Φ80×80 Double wheels | |
| Bearing wheel size | mm | Φ115×55 | |
| Dimension | Min. fork lowered height | mm | 85 |
| Max. fork lifting height | mm | 205 | |
| Max. lifting height | mm | 120 | |
| Overall fork width | mm | 540/600/685/1070 | |
| Fork length | mm | 1150/1200 | |
| Fork width | mm | 185 | |
| Fork thickness | mm | 55 | |
| Overall length (pedal folded/unfolded) | mm | 1900/2305 | |
| Overall width | mm | 735 | |
| Overall height (with/without handle) | mm | 1455/900 | |
| Min. turning radius (pedal folded/unfolded) | mm | 1735/2140 | |
| Min. aisle width for pallets 1000×1200 | mm | 2090/2468 | |
| Min. aisle width for pallets 800×1200 | mm | 2060/2451 | |
| Performance | Travel speed laden/unladen | km/h | 5.7/6 |
| Travel speed laden/unladen | mm/s | 30/45 | |
| Decline speed laden/unladen | mm/s | 45/30 | |
| Gradeability laden/unladen | % | 6/8 | |
| Electric configuration | Drive motor power | kw | AC1.5/2.2 |
| Lift motor power | kw | DC2.0 | |
| Control system | DC0.15 | ||
| Standard battery voltage/capacity | V/Ah | 24/210-240 | |
| Brake | Electromagnetic/Regenerative | ||
| Controller | CURTIS | ||
| Weight | Battery weight | kg | 200-230 |
| Service weight with battery | kg | 790-820 |
