3.5ton LPG Forklift,4.5m Triplex Mast,side Shifter

3.5ton LPG Forklift,4.5m Triplex Mast,side Shifter thumbnail-1
3.5ton LPG Forklift,4.5m Triplex Mast,side Shifter photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
GP
Contact Supplier Request Quote Chat Now
Shanghai Gather Power Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name GP
Model Number CPQ(Y)D35
Type Powered Pallet Truck
Power Souce Gasoline Engine
Rated Loading Capacity 3500kg
Max. Lifting Height 6000mm
Min. Lifting Height 2085mm
Fork Length 1070mm
Fork Width 125mm
Certification ISO&CE
After-sales Service Provided Overseas service center available

Specifications

GQ-4Y engine
TCM transmission
IMPCO converter
pneumatic tyre

model   CPQ(Y)20 CPQ(Y)D20 CPQ(Y)25 CPQ(Y)D25 CPQ(Y)30 CPQ(Y)D30 CPQ(Y)35 CPQ(Y)D35
load capacity kg 2000 2500 3000 3500
load center mm 500
wright with load kg 4740/660 5475/805 6420/930 7400/950
weight without load kg 1440/1960 1475/2305 1790/2560 2030/2820
drive speed km/h 20/19.5
turning radius mm 2170 2230 2420 2490
Min.barcket routeway mm 1920 2000 2120 2190
towing force kn 1170 1210 1246 1650
gradeability % 20 18 15 16.5
lifting speed mm/s 500/530 470/520 330/370
lowering speed mm/s 600
complete size mm 2517*1160 2572*1160 2695*1230 2765*1230
over guard height mm 2070 2085
mast height mm 1995 2055 2155
lifting height mm 4239 4256 4356
fork size mm 920*122*40 1070*125*45 1070*125*45 1070*125*50
wheel distance mm 970/970 1000/970
work pressure mpa 17.5 18
engine model   JAPAN MITSUBISHI4G64/NISSAN/HW491
rate power/speed kw/r.p.m. 37/2500/42/2400
engine rate torque kw/r.p.m. 161/1600/161/1800
engine displacement L 2.35/2.24
gearbox change speed type   mechnical/hydraulic
front tire type   7.00-12-12PR 28*9-15-12PR
behind tire type   6.00-9-10PR 6.50-10-10PR
gear type   CBFZ-F32ALHX
full tank capacity L 52
wheel air pressure mpa 0.7
total weight kg 3550 3880 4380 4750
