1.8ton Gasoline&LPG Forklift

1.8ton Gasoline&LPG Forklift thumbnail-1
1.8ton Gasoline&LPG Forklift photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
GP
Contact Supplier Request Quote Chat Now
Shanghai Gather Power Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name GP
Model Number CPQ(Y)D18
Type Other, gasoline forklift
Power Souce Gasoline Engine
Rated Loading Capacity 1.8Ton
Max. Lifting Height 6000mm
Min. Lifting Height 2500mm
Fork Length 920mm
Fork Width 120mm
Overall Dimensions 3155mm
Certification ISO&CE
After-sales Service Provided Overseas service center available

Specifications

1.USA IMPCO LPG system
2.Japan NISSAN engine
3.TCM technology
4.CE and ISO certificates

General   Manufacturer   GP
1 Model   CPQD10 CPQD15 CPQD18
CPQ10 CPQ15 CPQ18
2 Rated capacity kg 1000 1500 1800
3 Load center mm 500
4 Gearbox change speed type   Hydraulic/Mechanical
5 Power type   Gasoline / LPG
6 Tire type Front/Rear   Pneumatic
7 Wheels Front/Rear   2*2/2
Dimensions 8 Lift height mm 3000
9 Free lift height mm 162
10 Fork size L*W*T mm 920*122*40
11 Mast tilt angle Fwd/Bwd deg 6/12
12 Overall length (without fork) mm 2180 2235 2270
13 Overall width mm 1080
14 Mast height fork lowered mm 1995
15 Overall height fork raised mm 4042
16 Overall height (overhead guard) mm 2075
17 Turning radius (outside) mm 1890 1960 2000
18 Load distance (centerline of front axle to front face of forks) mm 429
19 Minimum Aisle -90 stack(Add load length and clearance) mm 1740 1780 1820
20 Wheel base mm 1400
21 Tread Front mm 890
22 Rear mm 920
23 Min. Under-clearance Bottom of mast mm 95 85
24 Bottom of frame mm 105
Performance 25 Speed Travel Max. With load km/h 13.5
26 Without load km/h 14.5
27 Lifting With load km/h 450
28 Without load km/h 510
29 Lowering With load km/h 450
30 Without load km/h 550
31 Max. Drawbar pull With/without load kg 1250/850 1250/850 1100/1000
32 1650/850 1650/850 1350/1000
33 Max.Gradeability With/without load % (fan) 20
21
Weight 34 Service weight kg 2340 2740 2943
35 Weight distribution With load Front kg 3410 3790 4170
36 Rear kg 370 450 570
37 Without load Front kg 1016 1096 1175
38 Rear kg 1564 1644 1765
Tyre 39 Tyre Size Front   6.50-10-10PR
40 Rear   5.00-8-8PR 5.00-8-10PR
Brake 41 Brake Service   Hydraulic-Foot pedal
42 Parking   Mechanical-Hand lever
Transmission 43 Battery Voltage / Capacity V/AH 12/80
44 Internal combustion engine Model   MITSUBISHI / NISSAN / GQ-4Y
45 Rated horsepower Kw/rpm 31.2/2250
46 Rated torque N.m/rpm 143/1600
47 Number of cylinder   4
48 Displacement cc 2.065
49 Fuel tank capacity lit 38
50 Transmission Type   Hydraulic/Mechanical
51 Shift (Fwd/Rvs)   1/1 (2/2)
  52 Work pressure Mpa 17.5
