Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
GP
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Shanghai, China
Brand Name
GP
Model Number
CPQYD30
Type
Powered Pallet Truck
Power Souce
LP Gas Engine
Rated Loading Capacity
3000KG
Max. Lifting Height
3M
Min. Lifting Height
0M
Fork Length
1070mm
Fork Width
125mm
Overall Dimensions
1070*125*45mm
Specifications
1.NISSAN K21,MITSUBISHI 4G64 , TOYOTA engine available2.Swiss bucher pump
3.Energy-efficient hydraulic system
Technical Specification:
| General | Manufacturer | GP | |||||||
| 1 | Model | CPQYD20 | CPQYD25 | CPQYD30 | CPQYD35 | ||||
| CPQ20 | CPQ25 | CPQ30 | CPQ35 | ||||||
| 2 | Rated capacity | kg | 2000 | 2500 | 3000 | 3500 | |||
| 3 | Load center | mm | 500 | ||||||
| 4 | Gearbox change speed type | Hydraulic/Mechanical | |||||||
| 5 | Power type | Gasoline / LPG | |||||||
| 6 | Tire type | Front/Rear | Pneumatic | ||||||
| 7 | Wheels | Front/Rear | 2*2/2 | ||||||
| Dimensions | 8 | Lift height | mm | 3000 | |||||
| 9 | Free lift height | mm | 140 | 145 | 150 | ||||
| 10 | Fork size | L*W*T | mm | 920*122*40 | 1070*122*40 | 1070*125*45 | 1070*130*45 | ||
| 11 | Mast tilt angle | Fwd/Bwd | deg | 6/12 | |||||
| 12 | Overall length (without fork) | mm | 2513 | 2583 | 2698 | 2725 | |||
| 13 | Overall width | mm | 1150 | 1225 | 1225 | ||||
| 14 | Mast height fork lowered | mm | 1995 | 2070 | 2160 | ||||
| 15 | Overall height fork raised | mm | 4030 | 4250 | 4356 | ||||
| 16 | Overall height (overhead guard) | mm | 2070 | 2090 | |||||
| 17 | Turning radius (outside) | mm | 2170 | 2240 | 2400 | 2450 | |||
| 18 | Load distance (centerline of front axle to front face of forks) | mm | 483 | 498 | |||||
| 19 | Minimum Aisle -90 degree stack(Add load length and clearance) | mm | 2640 | 2710 | 2885 | ||||
| 20 | Wheel base | mm | 1600 | 1700 | |||||
| 21 | Tread | Front | mm | 970 | 1000 | ||||
| 22 | Rear | mm | 970 | ||||||
| 23 | Min. Under-clearance | Bottom of mast | mm | 110 | 135 | 145 | |||
| 24 | Bottom of frame | mm | 115 | 140 | 140 | ||||
| Performance | 25 | Speed | Travel Max. | With load | km/h | 17 | 18 | ||
| 26 | Without load | km/h | 19.5 | 19.5 | |||||
| 27 | Lifting | With load | km/h | 570 | 450 | 380 | |||
| 28 | Without load | km/h | 600 | 500 | 450 | ||||
| 29 | Lowering | With load | km/h | 450 | 420 | ||||
| 30 | Without load | km/h | 550 | 500 | 460 | ||||
| 31 | Max. Drawbar pull | With/without load | kg | 1250/850 | 1250/850 | 1100/1000 | 1304/1190 | ||
| 32 | 1650/850 | 1650/850 | 1350/1000 | 1696/1190 | |||||
| 33 | Max.Gradeability | With/without load | % (fan) | 20/20 | 17/18 | 15/18 | 15/18 | ||
| 21/22 | 18/19 | 19/20 | 15/18 | ||||||
| Weight | 34 | Service weight | kg | 3410 | 3770 | 4370 | 4750 | ||
| 35 | Weight distribution | With load | Front | kg | 4730 | 5480 | 6455 | 7320 | |
| 36 | Rear | kg | 590 | 700 | 825 | 930 | |||
| 37 | Without load | Front | kg | 1520 | 1465 | 1720 | 2040 | ||
| 38 | Rear | kg | 1800 | 2215 | 2560 | 2710 | |||
| Tyre | 39 | Tyre | Size | Front | 7.00-12-12PR | 28*9-15-12PR | |||
| 40 | Rear | 6.00-9-10PR | 6.50-10-10PR | ||||||
| Brake | 41 | Brake | Service | Hydraulic-Foot pedal | |||||
| 42 | Parking | Mechanical-Hand lever | |||||||
| Transmission | 43 | Battery | Voltage / Capacity | V/AH | 12/100 | ||||
| 44 | Internal combustion engine | Model | MITSUBISHI / NISSAN / HW491/ GQ-4Y | ||||||
| 45 | Rated horsepower | Kw/rpm | 42.5/2500 | 45.6/2700 | |||||
| 46 | Rated torque | N.m/rpm | 161/1600 | 185/1600 | |||||
| 47 | Number of cylinder | 4 | |||||||
| 48 | Displacement | cc | 2.35 | 2.488 | |||||
| 49 | Fuel tank capacity | lit | 70 | 70 | |||||
| 50 | Transmission | Type | Hydraulic/Mechanical | ||||||
| 51 | Shift (Fwd/Rvs) | 1/1 (2/2) | |||||||
| 52 | Work pressure | Mpa | 17.5 | ||||||
